Q TRANSMIT POWER SWITCH [H/L/DTMF]
Selects high or low transmit output power. (p. 16) —
While pushing this switch and rotating the tuning control,
the low output power level changes. (p. 17)
While pushing [F], push this switch to enter DTMF
MEMORY mode. (p. 29)
MONITOR SWITCH [MONI]
Opens the squelch and optional tone squelch. (p. 16)
Checks the transmit frequency when duplex is selected.
(р. 17) -
While pushing [F], push this switch to turn OFF the
green receive indicator. This function conserves battery
pack power. (p. 16)
LIGHT SWITCH [LIGHT]
Lights the display backlight for approx. 5 sec.
While pushing [F], push this switch for continuous
lighting. To turn OFF, push this switch again.
While pushing this switch together with some digit keys,
turn power ON to initialize the scan resume condition
(p. 25), power saver duty cycle (p. 33) or PTT switch
function. (p. 17)
©
10
Ф
PANEL DESCRIPTION 4
H
i
FUNCTION SWITCH · [Е]
While pushing this switch, other switches function as a
secondary function.
PTT SWITCH [PTT]
Push and hold to transmit; release to receive.
BATTERY PACK RELEASE BUTTON
Opens the latch for bottom cap removal when pushed
upwards. (p. 4)
