ABOUT THIS DOCUMENT
1
About this document
1.1
Function of this document
1.2
Scope
1.3
Target groups of these operating instructions
1.4
Further information
8
O P E R A T I N G I N S T R U C T I O N S | microScan3 – EtherNet/IP™
These operating instructions contain the information needed during the life cycle of the
safety laser scanner.
Operating instructions of the safety laser scanner must be made available to all people
who work with the device.
Read the operating instructions carefully and ensure that you have understood the con‐
tents completely before you work with the safety laser scanner.
The operating instructions apply to the microScan3 safety laser scanner with the follow‐
ing type label entry in the Operating Instructions field:
•
8020198
This document is included with the following SICK part numbers (this document in all
available language versions):
•
8020198
Some chapters of these operating instructions are intended for certain target groups.
However, the entire operating instructions are relevant for intended use of the product.
Table 1: Target groups and selected chapters of these operating instructions
Target group
Project developers (planners, developers,
designers)
Installers
Electricians
Safety experts (such as CE authorized repre‐
sentatives, compliance officers, people who
test and approve the application)
Operators
Maintenance personnel
www.sick.com
The following information is available via the Internet:
•
Further language versions of these operating instructions
•
Data sheets and application examples
•
CAD data of drawings and dimensional drawings
•
Certificates (such as the EU declaration of conformity)
Chapter of these operating instructions
"Project planning", page 25
"Configuration", page 80
"Technical data", page 157
"Accessories", page 189
"Mounting", page 69
"Electrical installation", page 77
"Project planning", page 25
"Configuration", page 80
"Commissioning", page 123
"Technical data", page 157
"Checklist for initial commissioning and com‐
missioning", page 200
"Operation", page 127
"Troubleshooting", page 141
"Maintenance", page 134
"Troubleshooting", page 141
