- Page 1 M O U N T I N G I N S T R U C T I O N S microScan3 – EFI-pro, microScan3 – EtherCAT®, microScan3 – PROFINET (M12), microScan3 – EtherNet/IP™ Safety laser scanners...
- Page 2 M O N T A G E A N L E I T U N G microScan3 – EFI-pro, microScan3 – EtherCAT®, microScan3 – PROFINET (M12), microScan3 – EtherNet/IP™ Sicherheitslaserscanner...
-
Page 3: Zu Diesem Dokument
Den beiliegenden Sicherheitshinweis beachten. 8020210/1H7G/2022-10-19 | SICK M O N T A G E A N L E I T U N G | microScan3 – EFI-pro, microScan3 – EtherCAT®, microScan3 – PROFINET (M12), microScan3 –... - Page 4 2,25 Nm … 2,75 Nm. M O N T A G E A N L E I T U N G | microScan3 – EFI-pro, microScan3 – EtherCAT®, microScan3 – PROFINET (M12), microScan3 8020210/1H7G/2022-10-19 | SICK – EtherNet/IP™ Irrtümer und Änderungen vorbehalten...
- Page 5 Anschlussbelegung Spannungsversorgung (XD1) Stecker, M12, 4-polig, A-codiert. 8020210/1H7G/2022-10-19 | SICK M O N T A G E A N L E I T U N G | microScan3 – EFI-pro, microScan3 – EtherCAT®, microScan3 – PROFINET (M12), microScan3 – EtherNet/IP™...
- Page 6 Funktion des Anschlusses siehe „Anschlussübersicht“. M O N T A G E A N L E I T U N G | microScan3 – EFI-pro, microScan3 – EtherCAT®, microScan3 – PROFINET (M12), microScan3 8020210/1H7G/2022-10-19 | SICK – EtherNet/IP™ Irrtümer und Änderungen vorbehalten...
- Page 7 „Systemste‐ cker tauschen“. 8020210/1H7G/2022-10-19 | SICK M O N T A G E A N L E I T U N G | microScan3 – EFI-pro, microScan3 – EtherCAT®, microScan3 – PROFINET (M12), microScan3 – EtherNet/IP™ Irrtümer und Änderungen vorbehalten...
- Page 8 Schraubenschlüssel Innensechsrund TX20 M O N T A G E A N L E I T U N G | microScan3 – EFI-pro, microScan3 – EtherCAT®, microScan3 – PROFINET (M12), microScan3 8020210/1H7G/2022-10-19 | SICK – EtherNet/IP™ Irrtümer und Änderungen vorbehalten...
- Page 9 8020210/1H7G/2022-10-19 | SICK M O N T A G E A N L E I T U N G | microScan3 – EFI-pro, microScan3 – EtherCAT®, microScan3 – PROFINET (M12), microScan3 – EtherNet/IP™ Irrtümer und Änderungen vorbehalten...
- Page 10 M O U N T I N G I N S T R U C T I O N S microScan3 – EFI-pro, microScan3 – EtherCAT®, microScan3 – PROFINET (M12), microScan3 – EtherNet/IP™ Safety laser scanners...
-
Page 11: About This Document
Observe the enclosed safety notes. 8020210/1H7G/2022-10-19 | SICK M O U N T I N G I N S T R U C T I O N S | microScan3 – EFI-pro, microScan3 – EtherCAT®, microScan3 – PROFINET (M12), microScan3 –... -
Page 12: Device Overview
To do so, enter the product part number in the search field (part number: see the entry in the “P/N” or “Ident. no.” field on the type label). -
Page 13: Connection Overview
Voltage supply (XD1) Male connector, M12, 4-pin, A-coded. 8020210/1H7G/2022-10-19 | SICK M O U N T I N G I N S T R U C T I O N S | microScan3 – EFI-pro, microScan3 – EtherCAT®, microScan3 – PROFINET (M12), microScan3 –... -
Page 14: Replacing The Safety Laser Scanner
If the safety laser scanner is damaged or defective, you must replace it. M O U N T I N G I N S T R U C T I O N S | microScan3 – EFI-pro, microScan3 – EtherCAT®, microScan3 – PROFINET (M12), 8020210/1H7G/2022-10-19 | SICK microScan3 – EtherNet/IP™... - Page 15 Check the effectiveness of the protective device. For more information, see the operating instructions. 8020210/1H7G/2022-10-19 | SICK M O U N T I N G I N S T R U C T I O N S | microScan3 – EFI-pro, microScan3 – EtherCAT®, microScan3 – PROFINET (M12), microScan3 –...
-
Page 16: Replacing The System Plug
M O U N T I N G I N S T R U C T I O N S | microScan3 – EFI-pro, microScan3 – EtherCAT®, microScan3 – PROFINET (M12), 8020210/1H7G/2022-10-19 | SICK microScan3 – EtherNet/IP™... - Page 17 8020210/1H7G/2022-10-19 | SICK M O U N T I N G I N S T R U C T I O N S | microScan3 – EFI-pro, microScan3 – EtherCAT®, microScan3 – PROFINET (M12), microScan3 – EtherNet/IP™...
- Page 18 E-Mail office@sick.com.gr E-Mail info@sick.ru Vietnam Hong Kong Singapore Phone +65 6744 3732 Phone +852 2153 6300 Phone +65 6744 3732 E-Mail sales.gsg@sick.com E-Mail ghk@sick.com.hk E-Mail sales.gsg@sick.com Detailed addresses and further locations at www.sick.com SICK AG | Waldkirch | Germany | www.sick.com...
