TECHNICAL DATA
162 O P E R A T I N G I N S T R U C T I O N S | microScan3 – EtherNet/IP™
Length of cable
Fieldbus/industrial network
Type of fieldbus integration
Connection type
Supported protocol versions
Electrical data
Table 38: Electrical data
Operating data
Protection class
Supply voltage U
V
Residual ripple
Start-up current at 24 V
Current consumption at 24 V
Operation ≤ 0.45 A (typ. 0.3 A)
Sleep mode Typ. 0.29 A
Power consumption
Operation ≤ 11 W (typ. 7.2 W)
Sleep mode Typ. 7 W
Power-up delay
1) The power supply unit must be able to jumper a brief power failure of 20 ms as specified in
IEC 60204-1. Suitable power supply units are available as accessories from SICK.
2) The voltage level must not fall below the specified minimum voltage.
Mechanical data
Table 39: Mechanical data
Dimensions (without system
plug, W × H × D)
Weight (including system
plug)
Housing material
Housing color
Optics cover material
Optics cover surface
microScan3 Core –
EtherNet/IP™
≤ 5 m
EtherNet/IP
M12 female connector, 4-pin,
D-coded
• Common Industrial Protocol: The CIP Networks Library Vol‐
ume 1, Edition 3.20
• EtherNet/IP™: The CIP Networks Library Volume 2, Edition
1.21
• CIP Safety™: The CIP Networks Library Volume 5, Edition
2.13
microScan3 Core –
EtherNet/IP™
III (IEC 61140)
24 V DC (16.8 V ... 30 V DC)
(SELV/PELV)
1)
± 5%
2)
≤ 3 A
≤ 45 s (typ. 20 s)
microScan3 Core –
EtherNet/IP™
112 mm × 150.8 mm × 111.1 mm
1.45 kg
Aluminum
RAL 9005 (black) and RAL 1021 (colza yellow)
Polycarbonate
Outside with scratch-resistant coating
microScan3 Pro –
EtherNet/IP™
≤ 5 m
Female connector, M12, 4-pin,
D-coding
microScan3 Pro –
EtherNet/IP™
III (IEC 61140)
24 V DC (16.8 V to 30 V DC)
(SELV/PELV)
1)
≤ 0.45 A (typ. 0.3 A)
≤ 45 s (typ. 20 s)
microScan3 Pro –
EtherNet/IP™
