Deleting the assignment of a field set from the monitoring case
Drag the field set from the monitoring case table onto the trash-can icon.
b
✓
The field set is removed from the relevant monitoring case.
Defined cut-off behavior
DANGER
Hazard due to lack of effectiveness of the protective device
Persons and parts of the body to be protected may not be recognized in case of non-
observance.
The function Always ON has the same effect as a field which is always clear. In a monitor‐
ing case with the Always ON function, the cut-off path containing this function is perma‐
nently in the ON state.
Drag the Always OFF function onto the cut-off path.
b
✓
The field is viewed as being permanently interrupted.
If the monitoring case becomes active, the cut-off path is always in the OFF state.
Drag the Always ON function onto the cut-off path.
b
✓
The field is viewed as being permanently clear.
If the monitoring case becomes active, the cut-off path is always in the ON state.
If fields have not been assigned to certain cells in a monitoring case table, Safety
Designer assigns the Always OFF function to these cells.
