Name
SafeCutOffPath01
SafeCutOffPath02
...
SafeCutOffPath08
NonsafeCutOffPath01
NonsafeCutOffPath02
...
NonsafeCutOffPath08
Current Monitoring Case No
(Table 1)
ResetRequiredCutOffPath01
ResetRequiredCutOffPath02
...
ResetRequiredCutOffPath08
StandbymodeActive
8020200/15ZT/2019-11-14 | SICK
Subject to change without notice
Use Data type
Safety function BOOL
Safety function BOOL
Additional func‐ BOOL
tion
Additional func‐ BOOL
tion
Diagnostics USINT
Diagnostics BOOL
Diagnostics BOOL
Diagnostics BOOL
Definition Values
Cut-off path 01 (safety- 0 = OFF state,
oriented) protective field
interrupted
The signal is ON if the
currently monitored
1 = ON state,
field in the cut-off path
protective field
is safety-related and
free
free.
Cut-off path 02 ... 08 0 = OFF state,
(safety-oriented) protective field
interrupted
The signal is ON if the
currently monitored
1 = ON state,
field in the cut-off path
protective field
is safety-related and
free
free. 1)
Cut-off path 01 (Not 0 = OFF state,
safety-related) field interrupted
The signal is ON if the
1 = ON state,
currently monitored
field free
field in the cut-off path
is free.
Cut-off path 02 ... 08 0 = OFF state,
(Not safety-related) field interrupted
The signal is ON if the
1 = ON state,
currently monitored
field free
field in the cut-off path
is free.
1)
Current monitoring 0 = no monitor‐
case (Monitoring case ing case is active
table 1)
1 ... 254 = num‐
Signalizes the current
ber of the current
(active) monitoring case
(active) monitor‐
of monitoring case
ing case
table 1.
Reset required, Cut-off 0 = reset not
path 01 required
Signalizes whether the
1= reset required
device is waiting for a
reset signal to switch
safety-related cut-off
path 01 to the ON
state.
Reset required, Cut-off 0 = reset not
path 02 ... 08 required
Signals whether the
1= reset required
device is waiting for a
reset signal to switch
the respective safety-
related cut-off path to
the ON state.
1)
Status sleep mode 0 = device not in
sleep mode
Signalizes whether the
device is in sleep
1 = device in
mode.
sleep mode
