SICK microScan3 EtherNet/IP Operating Instructions Manual page 170

13
TECHNICAL DATA
13.6.1.2 Assembly object (0x04)
170 O P E R A T I N G I N S T R U C T I O N S | microScan3 – EtherNet/IP™
Attribute ID Access rule
Dec Hex
7 0x07 Get
Services
• Get_Attributes_All
• Get_Attribute_Single
Object instance
Attribute ID Access rule
Dec Hex
1 0x01 Get
2 0x02 Get
3 0x03 Get
4 0x04 Get
5 0x05 Get
6 0x06 Get
7 0x07 Get
8 0x08 Get
9 0x09 Get
Services
• Get_Attributes_All
• Get_Attribute_Single
Available instances
•
ID1
Object class
Attribute ID Access rule
Dec Hex
1 0x01 Get
Services
• Get_Attribute_Single
Object instance
Attribute ID Access rule
Dec Hex
3 0x03 Get/Set
4 0x04 Get
Services
• Get_Attribute_Single
Available instances
• ID100: Assembly 100: input of the device, output of the control
• ID103: Assembly 103: input of the device, output of the control
• ID110: Assembly 110: output of the device, input of the control
Name Data type
Max Number Instance UINT
Attributes
Name Data type
Vendor ID UINT
Device Type UINT
Product Code UINT
Revision STRUCT
Status WORD
Serial Number UDINT
Product Name SHORT_STRING
State USINT
Conf. Consistent. UINT
Value
Name Data type
Revision UINT
Name Data type
DATA ARRAY of BYTE
Number of bytes in UINT
ATTR 3
