The DCI Warranty does not cover any transmitter that has been
overheated or had the temp dot removed.
TRANSMITTER TEMPERATURE WARNINGS
STEP 1 OF 6
DigiTrak transmitters (Tx), with the exception of DucTrak, have an internal
digital thermometer. The normal below ground temp range is 63° – 104°F
(17° – 40°C). The Tx temperature displays on the bottom right of the locator
screen and remote display screens.
1. Temperature status icon
2. Temp trend up/down arrows
3. Temperature
Suspend drilling when temperatures increase rapidly.
Temperatures above 111°F (36°C) are not typical.
STEP 2 OF 6
As the transmitter (Tx) temperature increases above 61°F (16°C), the locator
and remote emit warning beeps and the temperature icon changes on the
locator or remote display.
