Walk back toward the RLP until the Locate Line (LL) appears.
If the LL does not appear, go to the FLP and hold the trigger to
show the predicted depth until the R appears.
STEP 9 OF 11
Ensure the locator is on the line connecting the two marked locate points.
Position the locator so the LL passes through the center of the box. The
transmitter housing should be beneath this point as long as the transmitter is
relatively level (see "Steep and Deep" under Advanced Topics).
The locator can face toward or away from the drill as long as it is
parallel to the direction of drilling.
