Digital Control DIGITRAK FALCON F1 SINGLEBAND User Manual page 59

STEP 8 OF 9
Select Transmitter Pairing
Request.
STEP 9 OF 9
Continue to pair and then calibrate the transmitter.
For step-by-step instructions, see the articles, "Advanced FO - Pair" and
"Calibrate Intro" in the Jobsite Setup chapter.
FALCON TRANSMITTER ADAPTER FOR V2 MULTIPOWER "BLUE"
TRANSMITTERS
FTA2 Falcon Transmitter Adapter is designed specifically for a single 21700
LiR (Lithium Rechargeable) battery with built-in protection. Falcon transmitter
runtime estimates are based on use of a 5,000 mAh battery with a max 4.2
volts. This adapter incorporates a lockout and is designed to fit the Blue DCI
Falcon Transmitters.
The FTA is not compatible with Falcon transmitters with green
tubes.
For a 21700 battery, insert the positive terminal first.
Battery Life
15-inch Blue V2 MultiPower Transmitters
High power: 8 hours
DIGITAL CONTROL, INC
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL
DCI DigiGuide 05.18.2024
59
