During Drilling
TURN ON HEIGHT-ABOVE-GROUND
STEP 1 OF 4
Things You Should Know
HAG must be turned on manually each time after the locator is powered on
or calibrated.
Target Steering assumes that the locator is on the ground, even
if standard HAG is enabled. If TrakStand HAG is enabled the
height set for the Trakstand is adjusted for Target Steering.
STEP 2 OF 4
From the Main menu, select
HAG.
STEP 3 OF 4
To enable standard HAG (hand-held) and the height shown on the screen is
acceptable, select Enable HAG. Otherwise, click Set HAG to enter a new
height.
DIGITAL CONTROL, INC
DIGITRAK FALCON F1 SINGLEBAND
USER MANUAL
DCI DigiGuide
05.18.2024
33
