The F1 is limited to frequency band 11. This band covers from
9.0 to 13.5 kHz. The Falcon F1 can be upgraded to an F2 with the
full suite of frequency bands.
BASIC - QUICK SCAN PAIR
STEP 1 OF 8
Before You Start
Basic - Quick Scan Pair scans noise and selects the best frequencies for band
11.
Use Advanced - Scan Pick Pair to view noise on the Frequency Optimizer.
STEP 2 OF 8
Ensure all transmitters are powered off or more than 100 ft (30.5 m) away
from the locator.
Inspect the job site and move locator to active noise area of concern or deep
part of bore - keep locator above and parallel to bore path.
STEP 3 OF 8
From the Main menu, select
Quick Scan Pair.
STEP 4 OF 8
Confirm the power mode. One bar is Low power mode and two bars is
Standard power mode. Falcon F1 locators do not have a High power mode.
DIGITAL CONTROL, INC
DIGITRAK FALCON F1 SINGLEBAND
USER MANUAL
DCI DigiGuide
05.18.2024
23
