1. Disable HAG
2. Enable standard HAG
3. Enable TrakStand HAG
4. Set HAG
5. Cancel
The locator must be held at this height for accurate depth
readings and is ignored during Target Steering.
STEP 4 OF 4
To enable TrakStand HAG,
select Enable TrakStand.
The height is preset to
1'6" (0.46m). This is the
height of a TrakStand
with legs fully extended.
The height of a
TrakStand with legs fully
collapsed is 1'9" (0.60m).
Changing the TrakStand height is not recommended. If the
height needs to be changed, return to the Enable HAG screen,
then select Set HAG to enter a new height. The custom height
will revert back to the pre-set after a power cycle.
DIGITAL CONTROL, INC
DIGITRAK FALCON F1 SINGLEBAND
USER MANUAL
DCI DigiGuide
05.18.2024
34
