DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 DIGITRAK FALCON F1 SINGLEBAND DCI DigiGuide User Manual 05.18.2024 Important Safety Info Bootcamp Initial Setup Jobsite Setup During Drilling Post Drilling Advanced Topics Troubleshooting Reference 19625 62nd Ave S Suite B103 Kent, WA 98032 U.S.
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 Important Safety Info GENERAL SAFETY WARNING Only operate your DCI guidance system in accordance with the operating instructions for your system. Serious injury and death, as well as property damage, can result if underground drilling equipment strikes a natural gas line, high-voltage electrical cable, or other utility.
Page 3
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 Ensure that all underground utilities have been located, exposed, and/or accurately marked prior to drilling. Follow all proper safety precautions, such as potholing. DCI equipment is not explosion-proof and should never be used near flammable or explosive substances.
Page 4
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 Interference levels change with time and with even minor changes in location. The frequency optimizer is not a substitute for prudent operator judgment. If performance drops while drilling, consider switching to the other selected band (not available on the Falcon F1) or use Max Mode.
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 Vehicles Saltwater/salt domes Conductive earth, such as iron ore If you have any questions about the operation of your guidance system, please contact DCI Customer Service for assistance. ENVIRONMENTAL REQUIREMENTS System working altitude: up to 6562 ft (2000m).
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 If you have any questions about the operation of your guidance system, please contact DCI Customer Service for assistance. EQUIPMENT AND BATTERY DISPOSAL This symbol on equipment indicates that the equipment must not be disposed of with your other household waste.
Page 7
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 Bootcamp HDD LOCATING HISTORY Locating in the horizontal directional drilling (HDD) industry was initially based on locating a buried cable by sweeping the locator back and forth to find the highest signal strength (peak signal), indicating that the locator was over the cable.
Page 8
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 There is a second locate point behind the transmitter called the Rear Locate Point (RLP). The two locate points, combined with a Locate Line (LL), pinpoint the precise location of the transmitter housing below ground.
Page 9
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 Passive interference consists of anything that blocks or distorts the transmitter signal resulting in incorrect depths or missing data. Example sources include rebar, guard rails, bridge abutments, chain link fencing, salt/saltwater, and soil high in metal ore. The Falcon sub-kHz transmitter (available for Falcon F5 and F5+ only) helps cut through passive interference without distorting the signal.
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 MENU NAVIGATION Use the trigger switch under the handle of your Falcon F1/F2 to navigate the menu system and select options. Click to open the Main menu and move between options.
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 LOCATE MODE SCREEN 1. Locating ball (FLP or RLP) 2. Locator 3. Roll indicator 4. Roll value 5. Roll/pitch update meter 6. Transmitter pitch 7. Power Mode (not available in legacy F1/F2) and Transmitter signal strength 8.
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 1. Locate point (front or rear) 2. Bird's-eye view 3. Locate Line (LL) 4. Height-Above-Ground (HAG) setting on 5. Ground level 6. Transmitter depth 7. Transmitter battery strength When the HAG setting is disabled, the locator displays at ground level and must be placed on the ground during depth readings.
Page 13
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 1. Ball-in-the-Box at FLP Reference Lock indicator * 3. Transmitter battery strength 4. Horizontal distance between transmitter and FLP Predicted depth * of transmitter The predicted depth is the depth the transmitter is calculated to be at when it reaches the FLP if it continues on its current path.
Page 14
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 predicted depth will also display when the locator is at the Rear Locate Point (RLP), but it will not be correct. DIGITAL CONTROL, INC...
Page 15
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 Initial Setup POWER ON STEP 1 OF 5 Check the charge level of your battery; each of the five lights on a li-ion battery represents about 20% capacity. NiMH batteries do not have a power meter. You can view battery life in the top banner of the Main menu.
Page 16
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 STEP 3 OF 5 Pull the trigger to turn on the locator. STEP 4 OF 5 Click to confirm you’ve read the manual. STEP 5 OF 5 Click again to continue.
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 See the DCI website for warranty terms and conditions. STEP 2 OF 2 Contact your authorized DCI dealer or DCI to register your equipment. You will need the equipment serial number and your company contact information.
Page 18
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 The circle is the where you can find the transmitter's region and model number. The region number is inside the globe icon in front of the serial number. STEP 2 OF 3...
Page 19
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 STEP 1 OF 5 Stuff You Should Know Use standard Height-Above-Ground (HAG) to set a height measurement on the locator so you don’t have to put it on the ground for a depth reading.
Page 20
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 Target Steering assumes that the locator is on the ground, even if standard HAG is enabled. If TrakStand HAG is enabled, the height set for the Trakstand is adjusted for Target Steering.
Page 21
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 Jobsite Setup POWER ON STEP 1 OF 5 Check the charge level of your battery; each of the five lights on a li-ion battery represents about 20% capacity. NiMH batteries do not have a power meter. You can view battery life in the top banner of the Main menu.
Page 22
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 STEP 3 OF 5 Pull the trigger to turn on the locator. STEP 4 OF 5 Click to confirm you’ve read the manual. STEP 5 OF 5 Click again to continue.
Page 23
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 The F1 is limited to frequency band 11. This band covers from 9.0 to 13.5 kHz. The Falcon F1 can be upgraded to an F2 with the full suite of frequency bands.
Page 24
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 To change the pre-set power level, click the Quick Scan/Pair option (the gear icon). STEP 5 OF 8 Insert batter(ies) positive terminal first and install the battery cap to power on the transmitter.
Page 25
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 STEP 7 OF 8 Select Transmitter pairing request. Do not move the transmitter until you hear four beeps and a check mark appears. STEP 8 OF 8 Confirm the pairing and power mode, and then click to continue to Calibration.
Page 26
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 STEP 4 OF 7 Select Frequency optimization. STEP 5 OF 7 Select Scan. STEP 6 OF 7 After the Band 11 bar appears on the right and the other bars disappear, walk your intended path.
Page 27
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 ADVANCED FO - PAIR STEP 1 OF 7 Things You Should Know Pairing sends the frequencies you selected to the transmitter. Pair a transmitter immediately after scanning with the Advanced method.
Page 28
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 To change the transmitter power mode, select Transmitter Power. Select the Band, and then click to cycle between the Standard and Low power modes. Hold and release to select the new power mode.
Page 29
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 Do not move the transmitter until you hear four beeps and a checkmark appears. STEP 7 OF 7 Confirm the pairing and power mode, and then click to continue to Calibration.
Page 30
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 CALIBRATE STEP 1 OF 8 Install the powered-on transmitter in the drill housing and install the cover. STEP 2 OF 8 Using a tape measure, place the near edge of the locator parallel to and exactly 10 ft (3 m) from the center of the transmitter.
Page 31
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 After a successful calibration, the locator beeps four times and displays a checkmark. If the calibration fails, the locator beeps two long beeps and displays an X. STEP 6 OF 8 Use the Above Ground Range (AGR) that displays next to check the accuracy of your calibration.
Page 32
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 STEP 7 OF 8 Click to exit to the Locate Mode screen. Verify you see the clock, pitch, and signal strength. STEP 8 OF 8 Fasten the drill housing cover properly before drilling.
Page 33
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 During Drilling TURN ON HEIGHT-ABOVE-GROUND STEP 1 OF 4 Things You Should Know HAG must be turned on manually each time after the locator is powered on or calibrated. Target Steering assumes that the locator is on the ground, even if standard HAG is enabled.
Page 34
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 1. Disable HAG 2. Enable standard HAG 3. Enable TrakStand HAG 4. Set HAG 5. Cancel The locator must be held at this height for accurate depth readings and is ignored during Target Steering.
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 The locator must be in the TrakStand at the set height for accurate depth readings. LOCATING THE TRANSMITTER STEP 1 OF 11 Find the Rear Locate Point (RLP) After the first rod has been drilled in, start at the entry point and face the direction of the bore.
Page 36
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 STEP 4 OF 11 Find the Front Locate Point (FLP) Walk forward. As you pass the transmitter, the ball jumps to the top of the screen. You are now tracking the Front Locate Point (FLP).
Page 37
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 STEP 6 OF 11 predicted depth * Hold the trigger to show the of the transmitter at this location. When the ball is centered in the box, hold the trigger for at least one second to lock onto the reference signal.
Page 38
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 Walk back toward the RLP until the Locate Line (LL) appears. If the LL does not appear, go to the FLP and hold the trigger to show the predicted depth until the R appears.
Page 39
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 STEP 10 OF 11 Hold the trigger to take a depth reading. If the signal strength is flashing, this indicates extreme interference. If you hold the trigger for longer than five seconds, the locator will enter...
Page 40
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 *PREDICTED DEPTH The Predicted Depth screen displays when the trigger is held with the locator at the Front Locate Point (FLP). The predicted depth is how deep the transmitter is calculated to be when it reaches the front locate point if it continues on its current path.
Page 41
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 STEP 6 OF 6 Click to exit. DIGITAL CONTROL, INC...
Page 42
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 Post Drilling LOCATOR AND BATTERY CARE STEP 1 OF 4 Select the Power icon in the second screen of the Main menu to power off the locator. STEP 2 OF 4 Remove the battery and inspect its contacts and those inside the battery compartment for corrosion and debris.
Page 43
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 TRANSMITTER AND BATTERY CARE STEP 1 OF 6 Remove the transmitter from the drill head. STEP 2 OF 6 Wipe the transmitter clean so dirt doesn’t enter the battery compartment or accumulate on the battery cap threads.
Page 44
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 STEP 6 OF 6 Store the transmitter in the original system carry case where it will be safe from impact and excessive temperatures. Storage and transportation temperature must remain within 40°...
Page 45
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 Advanced Topics STEEP AND DEEP When a transmitter is level (zero pitch) underground: the locate points (FLP and RLP) are at equal distances from the transmitter depth displayed on the locator is the actual depth, and the Locate Line (LL) indicates a position above the transmitter.
Page 46
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 1. RLP 2. FLP 3. LL 4. Fore/aft offset 5. Projected depth 6. Transmitter at positive pitch 7. 30% (17°) The differences in position and depth between the projected depth point and the actual location of the transmitter can be relatively small at low pitch and/or shallow depth.
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 Fore/Aft Offset For a given pitch, you can calculate actual or projected depth: MAX MODE STEP 1 OF 4 Before You Get Started Max Mode can stabilize roll/pitch data and depth readings when drilling at the transmitter’s range limit due to extreme depth or interference, which will...
Page 48
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 The drill head must be stationary when taking readings using Max Mode. If the drill head is moving, data readings will not be accurate. You will typically use Max Mode in areas where interference is high.
Page 49
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 1. Depth 2. Max Mode icon 3. Max Mode timer 4. Transmitter battery strength STEP 4 OF 4 Take two more Max Mode readings. All three readings must be consistent. If the readings are not consistent, change the band and try again.
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 Target Steering is typically only used on a straight drill path under level ground, not a curved path, with terrain changes, or to correct a significantly off-course bore. The maximum distance the locator can be placed ahead of the drill head for accurate up/down Target Steering is 35 ft (10.7 m).
Page 51
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 STEP 2 OF 5 The number on the screen shows the last target depth set. If it matches your desired target depth, select Target Steering. The remote screen at the drill will not display Target Steering until the locator is in Target Steering mode.
Page 52
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 If you go past 35 ft (10.7 m) do not rely on the depth and up/down steering information. Instead, monitor pitch data. 1. Horizontal distance from transmitter to locator 2. Current transmitter depth below the plane of the locator At this point, the drill rig operator uses the remote display to drill to the target.
Page 53
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 Select Disable Target Steering. GLOSSARY DEFINITIONS *TARGET DEPTH A value programmed into the locator, so it can be positioned ahead of the transmitter housing and used as a steering target. The value programmed should be the desired depth of the transmitter when it reaches the point below the locator.
Page 54
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 The transmitter does not need to be paired for the locator to read the transmitter info. STEP 3 OF 5 Select Transmitter Information. STEP 4 OF 5 Use the Transmitter Info screen to check important information such as...
Page 55
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 V2 TRANSMITTERS MULTIPOWER MODE INTRODUCTION When used with Falcon F1 locators, V2 transmitters have two power modes (Standard and Low) to balance signal strength and battery life. V2 transmitters are etched with a "V2" on the stainless battery compartment (not on the label) and have a multipower mode sticker around the IR port.
Page 56
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 1 For Falcon locators with programmable power mode, Low power also gives you a faster pitch update rate 2 Range is based on SAE Standard J2520 in AGR mode and Max Mode. Actual range and battery life will vary based on interference, transmitter housings, and frequencies.
Page 57
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 CHANGE V2 TX POWER MODE STEP 1 OF 9 Things You Should Know V2 Transmitters (V2 TX) have three power modes to balance signal strength and battery life. See the V2 Transmitter Power Mode introduction for how the power mode level affects depth readings and power level.
Page 58
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 STEP 3 OF 9 Select Frequency Optimization. STEP 4 OF 9 Select OK. STEP 5 OF 9 Click Select Transmitter Power. STEP 6 OF 9 Select the Band, and then toggle up or down through the High, Standard, and Low power modes, and then click to select the new power level.
Page 59
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 STEP 8 OF 9 Select Transmitter Pairing Request. STEP 9 OF 9 Continue to pair and then calibrate the transmitter. For step-by-step instructions, see the articles, "Advanced FO - Pair" and "Calibrate Intro"...
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 Standard power: 30 hours Low power: 60 hours Lithium Rechargeable (LiR) battery life is based on 21700 battery with 5000 mAh rating with a max 4.2 volts. For more information on MultiPower transmitters, see "V2 Transmitters MultiPower Mode Introduction."...
Page 61
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 The DCI Warranty does not cover any transmitter that has been overheated or had the temp dot removed. TRANSMITTER TEMPERATURE WARNINGS STEP 1 OF 6 DigiTrak transmitters (Tx), with the exception of DucTrak, have an internal digital thermometer.
Page 62
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 Tx temp: 61° – 97°F (16° – 36°C) Warning tones: Warning tones: Double beep (Beep-beep) for every 7°F (4°C) increase. Watch for an upward trend in temperatures. STEP 3 OF 6 Tx temp: 104°...
Page 63
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 STEP 5 OF 6 Tx temp: 140° F (60°C) and above (icon flashing) Warning tones: Three double beeps (Beep-beep, Beep-beep, Beep-beep) for every 20 seconds on the locator and 5 seconds on the remote display.
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 Troubleshooting MISSING ROLL AND PITCH STEP 1 OF 3 Double-check that your transmitter is powered on. a. Roll the transmitter 180°. They will fall asleep after 15 minutes of inactivity. b. If you do not have data and are above ground, move the transmitter closer to the locator.
Page 65
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 DEPTHS ARE INCORRECT STEP 1 OF 3 Verify calibration is correct above-ground. a. Measure out 10 feet (3 m) from the center of your housing to the inside edge of the locator.
Page 66
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 a. Start with the locator down at your side in the standard Locate Mode. b. Hold the trigger in and swing the locator out in front of your body. The locator should be pointed out like a radar gun.
Page 67
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 Reference FALCON F1 SPECIFICATIONS Product ID: FF1 Model number: FAR2 Receiving frequencies: 9.0–13.5 kHz Accuracy (1): ±5% of depth reading Telemetry channels (2): 4 Telemetry range (3): Up to 3000 ft (900 m) Target steering range (4): 35 ft (10.6 m)
Page 68
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 (1) Over specified depth range for each transmitter model. (2) Local telemetry frequencies and power levels are available at digital- control.com. (3) Telemetry range is dependent upon the remote display and optional external receiving antenna.
Page 69
Patents - https://www.digital-control.com/trademarks/ * Trademarks - Limited Warranty All products manufactured and sold by Digital Control Incorporated (DCI) are subject to the terms of a Limited Warranty. A copy of the Limited Warranty is https://www.digital-control.com/warranty/ * GLOSSARY DEFINITIONS COMPATIABLE TRANSMITTERS...
Page 70
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 Local regulations may prohibit the sale of certain transmitter variants in your region. If you have questions on availability, please contact orders@digital-control.com or productcompliance@digital-control.com. TELEMETRY USE RESTRICTIONS * Individual user licenses required for these countries. Check with your local authority.
Page 71
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 TRANSMITTER DRILL HOUSING REQUIREMENTS For maximum transmitter range and battery life, the slots in the drill head must meet minimum size requirements and be correctly positioned. DCI's transmitters require a minimum of three slots equally spaced around the circumference of the drill head.
Page 72
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 Slopes between 50% and 100% are provided for reference only and do not represent typical drilling conditions. All numbers are based on math only and do not take into account extremely soft or extremely hard soil conditions, which may cause depth values to vary.
Page 73
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 Slopes between 50% and 100% are provided for reference only and do not represent typical drilling conditions. All numbers are based on math only and do not take into account extremely soft or extremely hard soil conditions, which may cause depth values to vary.
Page 74
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 Slopes between 50% and 100% are provided for reference only and do not represent typical drilling condi tions. All numbers are based on math only and do not take into account extremely soft or extremely hard soil conditions, which may cause depth values to vary.
Page 75
DIGITRAK FALCON F1 SINGLEBAND USER MANUAL DCI DigiGuide 05.18.2024 Contact DCI USA DCI Australia DCI@digital-control.com DCI.Australia@digital-control.com US & CANADA AUSTRALIA 1.800.288.3610 +61.7.5531.4283 INTERNATIONAL INTERNATIONAL 1.425.251.0559 +61.7.5531.2617 DCI China DCI Europe DCI.China@digital-control.com DCI.Europe@digital-control.com CHINA EUROPE 400-100-8708 +49.9391.810.6100 INTERNATIONAL INTERNATIONAL +86.21.6432.5186 +49.9391.810.6109...
