*PREDICTED DEPTH
The Predicted Depth screen displays when the trigger is held with the locator at the
Front Locate Point (FLP). The predicted depth is how deep the transmitter is calculated
to be when it reaches the front locate point if it continues on its current path. The
predicted depth will also display when the locator is at the Rear Locate Point (RLP), but it
will not be correct.
*MAX MODE
Max Mode can stabilize roll/pitch data and depth readings when drilling at the
transmitter's range limit due to extreme depth or interference, which will vary by jobsite.
See the Max Mode topic for use and important safety information.
FIND THE SURFACE GRADE
STEP 1 OF 6
You can use your locator to display the degree of pitch of the terrain.
STEP 2 OF 6
Place the locator on the ground.
STEP 3 OF 6
To take a measurement on a slope, turn the locator sideways, and then tilt
the locator left or right so that the display screen is level.
STEP 4 OF 6
From the Main menu, go to
the second page and select
Level.
STEP 5 OF 6
The pitch is displayed in degrees.
DIGITAL CONTROL, INC
DIGITRAK FALCON F1 SINGLEBAND
USER MANUAL
DCI DigiGuide
05.18.2024
40
