1. Depth
2. Max Mode icon
3. Max Mode timer
4. Transmitter battery strength
STEP 4 OF 4
Take two more Max Mode readings. All three readings must be consistent.
If the readings are not consistent, change the band and try
again. If the readings continue to be inconsistent, turn the
locator off and then on again. If the issue continues, contact DCI
Customer Support.
TARGET STEERING INTRODUCTION
The Target Steering guidance method allows the Falcon locator to be placed
ahead of the drill head and used as a steering target.
Use it to distance the locator from rebar that is causing signal interference
and to drill where walkover locating is not possible.
DIGITAL CONTROL, INC
DIGITRAK FALCON F1 SINGLEBAND
USER MANUAL
DCI DigiGuide
05.18.2024
49
