Digital Control DIGITRAK FALCON F5+ User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
DIGITRAK FALCON F5+
USER MANUAL
DCI DigiGuide
11.04.2023
DIGITRAK FALCON F5+
DCI DigiGuide User Manual
11.04.2023
Important Safety Info
Bootcamp
Initial Setup
Jobsite Setup
During Drilling
Post Drilling
Advanced Topics
Troubleshooting
Reference
19625 62nd Ave S Suite B103 Kent, WA 98032 U.S.
DIGITAL CONTROL, INC
dci@digital-control.com | digital - control.com
1.800.288.3610 | 1.425.251.0559

Advertisement

loading
Need help?

Need help?

Do you have a question about the DIGITRAK FALCON F5+ and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Digital Control DIGITRAK FALCON F5+

Summary of Contents for Digital Control DIGITRAK FALCON F5+

  • Page 1 DCI DigiGuide User Manual 11.04.2023 Important Safety Info Bootcamp Initial Setup Jobsite Setup During Drilling Post Drilling Advanced Topics Troubleshooting Reference 19625 62nd Ave S Suite B103 Kent, WA 98032 U.S. DIGITAL CONTROL, INC dci@digital-control.com | digital - control.com 1.800.288.3610 | 1.425.251.0559...
  • Page 2 Also, when drilling steep and/or deep, the locate line may indicate a position behind or ahead of the transmitter. Please see "Steep and Deep" under Advanced Topics for important information about accurately locating the drill head when drilling steep and/or deep. DIGITAL CONTROL, INC...
  • Page 3 Interference can lead to inaccurate depth readings and/or interruption or loss of data. Never rely on data that does not display quickly and/or remain stable. The Falcon frequency optimizer selects frequencies based on measured interference at a specific time and location. DIGITAL CONTROL, INC...
  • Page 4 (material that can conduct or block electro-magnetic signals). Sources of interference may include: Active Traffic signal loops Buried dog fences Cathodic protection Radio communications Security systems Microwave towers Power, phone, fiber-trace and cable TV lines Passive Metal pipes Rebar Trench plates Chain-link fences DIGITAL CONTROL, INC...
  • Page 5 Failure to do so may result in short circuits, which may lead to hazardous conditions including fire. Lithium-ion batteries must be packaged and shipped by trained and certified personnel only. Never ship damaged batteries. DIGITAL CONTROL, INC...
  • Page 6 DIGITRAK FALCON F5+ USER MANUAL DCI DigiGuide 11.04.2023 If you have any questions about the operation of your guidance system, please contact DCI Customer Service for assistance. DIGITAL CONTROL, INC...
  • Page 7 You can purchase additional transmitters, batteries, and the R1 terrain mapper from your local dealer. You can find a chart of the compatible transmitters in the Reference Chapter in the "Compatible Transmitters" article. DIGITAL CONTROL, INC...
  • Page 8 DCI invented the Ball-in-the-Box user interface to make it quick and intuitive to find a locate point, speeding up drilling jobs: just move the locator so the ball moves into the box on the screen. DIGITAL CONTROL, INC...
  • Page 9 INTERFERENCE AND SIGNAL STABILITY Interference can cause incorrect locate data that reduces locating accuracy. There are two different types of interference that can distort the transmitter signal: active and passive. DIGITAL CONTROL, INC...
  • Page 10 Falcon’s frequency optimizer scans through hundreds of frequencies, then bundles those with the lowest noise into finely-tuned bands that work best for the current job. Select two bands and switch between them mid-bore if needed (not available on the Falcon F1 with singleband). DIGITAL CONTROL, INC...
  • Page 11 BENEFITS OF DATALOGGING Utilities increasingly require a digital as-built report to ensure drilling parameters were met. The DataLog® feature on your locator lets you easily capture and store the rod-by-rod data of your pilot bore. DIGITAL CONTROL, INC...
  • Page 12 Depth data appears when the trigger is held at the Locate Line (LL) and predicted depth appears when held at the Front Locate Point. LOCATE MODE SCREEN DIGITAL CONTROL, INC...
  • Page 13 DEPTH SCREEN The Depth screen displays when the trigger is held with the locator at the Locate Line (LL). 1. Locate point (front or rear) 2. Bird's-eye view 3. Locate Line (LL) 4. Height-Above-Ground (HAG) setting on DIGITAL CONTROL, INC...
  • Page 14 4. Horizontal distance between transmitter and FLP Predicted depth * of transmitter The predicted depth is the depth the transmitter is calculated to be at when it reaches the FLP if it continues on its current path. DIGITAL CONTROL, INC...
  • Page 15 The Predicted Depth screen displays when the trigger is held with the locator at the Front Locate Point (FLP). The predicted depth is how deep the transmitter is calculated to be when it reaches the front locate point if it continues on its current path. DIGITAL CONTROL, INC...
  • Page 16 You will need the equipment serial number and your company contact information. Here’s where to find your serial number: Locator: in the battery compartment Transmitter: engraved on the steel body Remote display: decal on the back POWER ON DIGITAL CONTROL, INC...
  • Page 17 Check the charge level of your battery; each of the five lights on a li-ion battery represents about 20% capacity. NiMH batteries do not have a power meter. You can view battery life in the top banner of the Main menu. STEP 2 OF 5 Insert battery in the locator. DIGITAL CONTROL, INC...
  • Page 18 STEP 1 OF 5 Before You Start You can change the language of the locator screens. The languages available are: English 汉语 (Chinese) Deutsch (German) िह ी, िहं द ी (Hindi) Español (Spanish) Русский (Russian) Français (French) DIGITAL CONTROL, INC...
  • Page 19 Select a language. The locator will beep four times and then restart. Changing the language on the locator does not change the language for remote displays, datalogging reports, or DDM. TRANSMITTER SETUP STEP 1 OF 3 Things you should know Your locating system can use different transmitters. DIGITAL CONTROL, INC...
  • Page 20 If you are using the Falcon Transmitter Adapter (FTA) with a battery, install Lithium Rechargeable (LiR) battery into the adapter positive terminal first. For more information on the FTA, see "Falcon Transmitter Adapter for V2 MultiPower "Blue" Transmitters" in the Advanced Topics chapter. DIGITAL CONTROL, INC...
  • Page 21 HAG must be turned on manually each time after the locator is powered on or calibrated. STEP 2 OF 7 To measure for standard HAG, hold the locator at your side as if you were holding a suitcase. DIGITAL CONTROL, INC...
  • Page 22 STEP 7 OF 7 When standard HAG is enabled, the locator must be held at the set height for accurate depth readings. HAG must be turned on manually each time after the locator is powered on or calibrated. DIGITAL CONTROL, INC...
  • Page 23 DIGITRAK FALCON F5+ USER MANUAL DCI DigiGuide 11.04.2023 Target Steering does not adjust depth for standard HAG and assumes the locator is on the ground. If TrakStand HAG is enabled, the locator adjusts for the TrakStand height. DIGITAL CONTROL, INC...
  • Page 24 Check the charge level of your battery; each of the five lights on a li-ion battery represents about 20% capacity. NiMH batteries do not have a power meter. You can view battery life in the top banner of the Main menu. STEP 2 OF 5 Insert battery in the locator. DIGITAL CONTROL, INC...
  • Page 25 STEP 1 OF 5 Stuff You Should Know Your locating system can use different transmitters. The transmitter selected on your locator must match the transmitter in use. See the "List of Compatible Transmitter" article in the Reference chapter. DIGITAL CONTROL, INC...
  • Page 26 STEP 2 OF 5 Main menu: If they do not match, use the following process to change the transmitter selection on the locator. STEP 3 OF 5 At the Main menu, select Transmitter selection. DIGITAL CONTROL, INC...
  • Page 27 After using one of the Advanced methods to pick the bands, you will pair them with the transmitter and then calibrate. Watch video on YouTube: Scan Pick Pair - English (1:52 min) https://youtu.be/pTEpehZ09A4 DIGITAL CONTROL, INC...
  • Page 28 - keep locator above and parallel to bore path. STEP 3 OF 7 From the Main menu, select Quick Scan Pair. Confirm the pre-selected bands and the power levels on the top box on the screen. DIGITAL CONTROL, INC...
  • Page 29 Insert batter(ies) positive terminal first and install the battery cap to power on the transmitter. STEP 5 OF 7 Align the transmitter so its IR port is near and facing the round IR port on the front of the locator. DIGITAL CONTROL, INC...
  • Page 30 You may decide to continue to use the currently selected bands or to select bands manually if you know you need a specific band, such as a low frequency band (7 or 11) to account for rebar or other interference. DIGITAL CONTROL, INC...
  • Page 31 Ensure all transmitters are powered off or more than 100 ft (30.5 m) away from the locator. STEP 3 OF 7 From the Main Menu, select Transmitter selection. STEP 4 OF 7 Select Frequency optimization. STEP 5 OF 7 Click the blue arrow to start scan. DIGITAL CONTROL, INC...
  • Page 32 This gives you the best frequencies for this location. You can continue to use the current bands, or use either the Quick Pick selections or select one or both new bands manually. DIGITAL CONTROL, INC...
  • Page 33 Down bands with the two bands indicated by the two white arrows. FO Wideband Screen STEP 2 OF 3 If you are using a FTR Sub-k transmitter the FO includes low frequency bands. Sub-k Frequency Optimizer Screen DIGITAL CONTROL, INC...
  • Page 34 If you are using a FTR Sub-k transmitter the FO includes low frequency bands. You can select 7, 11, or 16 for the Up band with Standard power and 0.3, 0.5, or 0.7 for the Down Band with Low power. DIGITAL CONTROL, INC...
  • Page 35 Insert battery(ies) positive terminal first and install the battery cap to power on the transmitter. To pair any other time, from the Main menu select Transmitter selection, Frequency optimization, and continue. STEP 2 OF 5 Confirm the Up and Down band and the power modes. DIGITAL CONTROL, INC...
  • Page 36 Align the transmitter so its IR port is near and facing the round IR port on the front of the locator. The Falcon Plus locators ignore the V2 Power Mode selection method described on the transmitter sticker and use the locator-specified power level. DIGITAL CONTROL, INC...
  • Page 37 Calibration is required any time you change your transmitter, locator, drill head, power setting, or perform a new frequency scan and then pair. Calibrate both bands with the transmitter in the housing (flat on the ground in a low-noise, metal-free environment) immediately after pairing. DIGITAL CONTROL, INC...
  • Page 38 Using a tape measure, place the near edge of the locator parallel to and exactly 10 ft (3 m) from the center of the transmitter. For accurate calibration, always use the center of the transmitter, not the drill head. DIGITAL CONTROL, INC...
  • Page 39 Use the Above Ground Range (AGR) that displays next to check the accuracy of your calibration. Move the locator to at least two different distances (5 ft/1.5m and 15 ft/4.6 m) and verify distance readings match the measurement. DIGITAL CONTROL, INC...
  • Page 40 Hold transmitter powered on at level (0±10°) for at least five seconds. STEP 2 OF 5 Tilt transmitter up at approximately +65° (almost vertical) for 10-18 seconds. STEP 3 OF 5 Return to level for 10-18 seconds. When the transmitters changes bands, data disappears from the locator. DIGITAL CONTROL, INC...
  • Page 41 Band Selection shortcut menu, and then select the desired Down band. STEP 5 OF 5 Select Locate Mode and verify that you see the clock, pitch, and signal strength. The red triangle in the roll indicator shows calibration is needed. DIGITAL CONTROL, INC...
  • Page 42 10 ft (3 m) from the center of the transmitter . For accurate calibration, always use the center of the transmitter, not the drill head. STEP 4 OF 7 Select Continue to calibrate the Down band. DIGITAL CONTROL, INC...
  • Page 43 STEP 6 OF 7 Click Cancel to exit to the Locate Mode screen. Verify you see clock, pitch, and signal strength. STEP 7 OF 7 Fasten the drill head cover properly before drilling. DIGITAL CONTROL, INC...
  • Page 44 STEP 3 OF 4 To enable standard HAG (hand-held), toggle to Enable HAG. If the height shown at the bottom of the screen is acceptable, select Enable HAG. Otherwise, click Set HAG to enter a new height. DIGITAL CONTROL, INC...
  • Page 45 It is not recommended to change the TrakStand Height. If needed, Enable Trakstand, return to the Enable HAG screen, and then select Set HAG to enter a new height. The custom height will revert back to the pre-set (1'6"/0.46m) after a power cycle. DIGITAL CONTROL, INC...
  • Page 46 Using the Locate Mode screen, move the locator to put the ball in the box. 1. Ball 2. Box STEP 3 OF 12 Mark this position on the ground as the Rear Locate Point (RLP). STEP 4 OF 12 Find the Front Locate Point (FLP) DIGITAL CONTROL, INC...
  • Page 47 STEP 5 OF 12 Move the locator to put the ball in the box. The locator can face toward or away from the drill as long as it is parallel to the direction of drilling. DIGITAL CONTROL, INC...
  • Page 48 Look back toward the RLP. The transmitter housing is positioned to travel toward you along the line connecting the RLP and FLP. STEP 9 OF 12 Find the Locate Line (LL) Walk back toward the RLP until the Locate Line (LL) appears. DIGITAL CONTROL, INC...
  • Page 49 (see "Steep and Deep" under Advanced Topics). The locator can face toward or away from the drill as long as it is parallel to the direction of drilling. STEP 11 OF 12 Hold the trigger to take a depth reading. DIGITAL CONTROL, INC...
  • Page 50 If you have a straight drill path but the FLP is to the left or right of the line projected from the previous locate points, this may indicate a drill head deflection or interference affecting the transmitter’s signal. GLOSSARY DEFINITIONS *PREDICTED DEPTH DIGITAL CONTROL, INC...
  • Page 51 STEP 2 OF 5 Observe signal strength drop after the drill operator completes a roll sequence to change bands. When using a wideband transmitter and the 10-2-7 roll sequence, transmitter data will disappear after a successful band change. DIGITAL CONTROL, INC...
  • Page 52 Toggle to and select the transmitter band without the X in the box (in this case, FT5p 7). STEP 5 OF 5 Select Locate Mode. FIND THE SURFACE GRADE STEP 1 OF 8 You can use your locator to display the degree of pitch of the terrain. DIGITAL CONTROL, INC...
  • Page 53 From the Main menu, toggle down to the second page and select Diagnostics. STEP 5 OF 8 Select Surface Grade. STEP 6 OF 8 The pitch is displayed in degrees. STEP 7 OF 8 To exit, click Cancel. DIGITAL CONTROL, INC...
  • Page 54 Watch a video and learn more. Some videos are only available in English. Please turn on subtitles and automatic translation. Watch video on YouTube: DigiTrak - Falcon F5 Training - How to display surface grade (1:23 min) https://youtu.be/JHJuc1SjweI DIGITAL CONTROL, INC...
  • Page 55 Store the battery and locator in the original system carry case safe from impact, moisture, and excessive temperatures. Do not store the battery in the battery charger or locator. Storage and transportation temperature must remain within -40° to 149°F (-40° to 65°C). DIGITAL CONTROL, INC...
  • Page 56 Clear any debris and replace the battery cap. Use conductive lubricant on the threads if the battery cap is difficult to turn. STEP 5 OF 6 Store batteries so they do not contact metallic objects or terminals of other batteries. DIGITAL CONTROL, INC...
  • Page 57 STEP 6 OF 6 Store the transmitter in the original system carry case where it will be safe from impact and excessive temperatures. Storage and transportation temperature must remain within 40° to 149° F (-40 to 65 °C). DIGITAL CONTROL, INC...
  • Page 58 When the transmitter is pitched up (positive pitch, shown below), the locate line on the screen reflects a position behind the transmitter. The depth reading on the locator is based on the projected depth point, which is not the same as the actual depth of the transmitter. DIGITAL CONTROL, INC...
  • Page 59 6'6" (2 m) ahead of the transmitter. You can use the pitch and the projected depth reading on your locator to determine the actual depth and the position (fore/aft) of the locate line: Actual Depth DIGITAL CONTROL, INC...
  • Page 60 This calibration procedure is rarely needed. If you find it necessary to calibrate with the transmitter in the ground, contact DCI customer service for information on this option, and perform the procedure with caution. MAX MODE STEP 1 OF 4 Before You Get Started DIGITAL CONTROL, INC...
  • Page 61 If the Max Mode timer fills up before depth and data stabilize, move to a different location near the drill head and hold to restart. The timer bar will turn green as data is confirmed. 1. Depth DIGITAL CONTROL, INC...
  • Page 62 Target Steering is 35 ft (10.7 m). Within this range, starting with the drill head approximately level, the maximum depth and pitch changes are approximately 4 ft (1.2 m) and 14%, respectively. Beyond this distance, depth information becomes less accurate. DIGITAL CONTROL, INC...
  • Page 63 STEP 3 OF 7 To change the target depth shown, use the keypad. If TrakStand HAG is enabled, but drilling shallower than 1.5 ft (0.5 m), adjust the TrakStand HAG height. DIGITAL CONTROL, INC...
  • Page 64 If you go past 35 ft (10.7 m) do not rely on the depth and up/down steering information. Instead, monitor pitch data. STEP 5 OF 7 1. Horizontal distance from transmitter to locator 2. Current transmitter depth below the plane of the locator DIGITAL CONTROL, INC...
  • Page 65 Note: If using a Falcon Compact Display, only left/right steering information is available. The locator used with the Falcon Compact Display must still have a target depth set. This target depth can be any value. ENABLE FULL SCALE SENSITIVE PITCH (FSSP) STEP 1 OF 3 Things You Should Know DIGITAL CONTROL, INC...
  • Page 66 To set the pitch units, go to Settings, select Pitch units in degrees, and then select percent or degrees. Falcon F2 and older Falcon F5 transmitters do not support FSSP mode and will not work in FSSP mode even if selected. GLOSSARY DEFINITIONS DIGITAL CONTROL, INC...
  • Page 67 "Find Best Frequencies" in the Jobsite Setup chapter describes how to run the interference * frequency optimizer, walk the bore to scan for , then optimize both bands at the point of highest noise. You need to be familiar with that topic before reading this one. DIGITAL CONTROL, INC...
  • Page 68 STEP 4 OF 10 Click the blue arrow to start the scan. STEP 5 OF 10 When the noise bars appear, walk the intended drill path to find the two locations with the highest levels of noise, then return DIGITAL CONTROL, INC...
  • Page 69 Otherwise, rescanning will erase the current frequencies. STEP 7 OF 10 Select Pair to pair and select power level. Skip calibration. STEP 8 OF 10 Move to the other location with high noise, return to Frequency Optimization, and scan again. DIGITAL CONTROL, INC...
  • Page 70 Target Steering capability. High bands have slightly less signal strength, but tend to offer better performance around active interference such as power lines. *BAND WITH THE LEAST NOISE DIGITAL CONTROL, INC...
  • Page 71 To change the band on the locator, from Locate Mode screen, hold the toggle right to open the Band Selection menu. Select the band without the checkmark. After a few seconds, data will begin to appear. DIGITAL CONTROL, INC...
  • Page 72 If no data is displayed on the Locate Mode screen, hold the toggle to the right to open the Band Selection shortcut menu. GET TRANSMITTER INFO STEP 1 OF 6 From the Main menu, select Transmitter selection. DIGITAL CONTROL, INC...
  • Page 73 Select Transmitter Information request. STEP 5 OF 6 Use the Transmitter Info screen to check important information such as runtime hours for warranty coverage, current band (green), operating battery voltage * current , and max recorded temperature. DIGITAL CONTROL, INC...
  • Page 74 If used with a Falcon without the programmable power mode, the mode selected while pairing the Tx determines the signal range and the battery life. Falcon locators with programmable power mode override any other selection method when used with a V2 transmitter. 19-in V2 Transmitters DIGITAL CONTROL, INC...
  • Page 75 DIGITRAK FALCON F5+ USER MANUAL DCI DigiGuide 11.04.2023 15-in V2 Transmitters For Falcon locators with programmable power mode, Low power also gives you a faster pitch update rate. Look for the rabbit icon. DIGITAL CONTROL, INC...
  • Page 76 You can also see the Power mode of the current band on the Locate Mode screen and the TX Info pairing screen. CHANGE V2 TX POWER MODE STEP 1 OF 9 From the Main menu, go to Transmitter Selection. DIGITAL CONTROL, INC...
  • Page 77 Frequency Optimizer, click Pair. The Up and Down bands will not change. If you also want to change one or both bands, select the Rescan icon. STEP 4 OF 9 Select Transmitter Power. DIGITAL CONTROL, INC...
  • Page 78 Toggle to the band (Up or Down) that you want to change, and then click to select. High Power requires Lithium-ion batteries. STEP 6 OF 9 Toggle up or down to toggle through the High, Standard, and Low power modes, and then click to select the new power level. DIGITAL CONTROL, INC...
  • Page 79 After changing the power level, you must re-pair the transmitter and then perform a 1 PT Calibration for each band changed. For step-by-step instructions, see the articles "Advanced FO - Pair" and "Calibrate Intro" in the Jobsite Setup chapter. DIGITAL CONTROL, INC...
  • Page 80 For a 21700 battery, insert the positive terminal first. Battery Life 19-Inch Blue V2 MultiPower Transmitters High power: 8 hours Standard power: 18 hours Low power: 44 hours 15-inch Blue V2 MultiPower Transmitters High power: 8 hours Standard power: 30 hours Low power: 60 hours DIGITAL CONTROL, INC...
  • Page 81 The temp dot has an outer yellow ring with a temperature sensitive 1/8" (3.15 mm) white dot in the center. If the center temp dot is black, the transmitter has been exposed to excessive heat and should no longer be used. DIGITAL CONTROL, INC...
  • Page 82 Temperatures above 111° F are not typical. STEP 2 OF 6 As the transmitter (Tx) temperature increases above 61° F, the locator and remote emits warning beeps and the temperature icon changes on the locator or remote display. DIGITAL CONTROL, INC...
  • Page 83 Tx temp: 118° to 133° F Warning tones: Three double beeps (beep-beep, beep-beep, beep-beep) for every 7° F increase. Cooling is critical to avoid irreversible damage. STEP 5 OF 6 Tx temp: 140° F and above (icon flashing) DIGITAL CONTROL, INC...
  • Page 84 Temperatures above 185° F may cause irreversible damage to the transmitter. STEP 6 OF 6 The transmitter records the maximum temperature that it has been exposed to. Use the Transmitter Info screen to view this information. See "Get Transmitter Info" for steps. DIGITAL CONTROL, INC...
  • Page 85 Check that the Transmitter is working. a. Check that you can view the transmitter info. If you can view data, the Tx is powered on, working, and can be paired. If you cannot view this screen, the transmitter may be damaged. DIGITAL CONTROL, INC...
  • Page 86 If you have a new transmitter, or locator, you must optimize, pair your frequencies, and recalibrate. For step-by-step instructions, go to Find Best Frequencies in the Jobsite Setup chapter. STEP 5 OF 5 If you still don't have roll and pitch data, call DCI for further troubleshooting. DIGITAL CONTROL, INC...
  • Page 87 If you do not have data and are above ground, insert fresh batteries. Lithium batteries will show 100% up until they’re nearly depleted. STEP 4 OF 6 Perform a Transmitter Information Request. a. On the Main menu, select Transmitter Selection. b. Select Transmitter Info. DIGITAL CONTROL, INC...
  • Page 88 Replace the batteries with recommended brands and perform another transmitter information request. Recommended brands are two C-cell Energizer alkaline batteries or one DCI SuperCell lithium battery. STEP 6 OF 6 If you are still unable to pair the transmitter, call DCI for further troubleshooting. DIGITAL CONTROL, INC...
  • Page 89 STEP 2 OF 6 Verify that your display on the drill is set to the correct locator. To change what locator your remote looks for click the main menu icon and then on the locator icon under Settings. DIGITAL CONTROL, INC...
  • Page 90 Ensure all internal pins are intact and clean with alcohol if connection points look dirty. STEP 5 OF 6 If not already in use, a filtered antenna may be necessary to reduce the effects of interference in the area. STEP 6 OF 6 Call DCI for further troubleshooting. DIGITAL CONTROL, INC...
  • Page 91 Dimensions: 11 x 5.5 x 15 in (27.94 x 13.97 x 38.1 cm) Weight (with battery): 8.4 lb (3.81 kg) Compatible Transmitters: See the article "List of Compatible Transmitters." Compatible Displays: Compatible remote displays: Aurora and FCD DIGITAL CONTROL, INC...
  • Page 92 DCI is responsible for FCC compliance in the United States. Changes or modifications to any DCI equipment not expressly approved and carried out by DCI will void the user’s Limited Warranty and the FCC’s authorization to operate the equipment. Digital Control Incorporated DIGITAL CONTROL, INC...
  • Page 93 For a list of restrictions, see the article, “Product CE Declarations of Conformity” can be found at www. digital-control.com * or upon request to productcompliance@digital- control.com. https://www.digital-control.com/patents/ * Patents - https://www.digital-control.com/trademarks/ * Trademarks - GLOSSARY DEFINITIONS DIGITAL CONTROL, INC...
  • Page 94 DIGITRAK FALCON F5+ USER MANUAL DCI DigiGuide 11.04.2023 TELEMETRY USE RESTRICTIONS * Individual user licenses required for these countries. Check with your local authority. COMPATIABLE TRANSMITTERS DIGITAL CONTROL, INC...
  • Page 95 Measure slot lengths on the inside of the drill head; slots must be at least 1/16th inch (1.6mm) wide. 1. Battery cap 2. Slot position 3. Front end cap A. Slot length B. Slot position C. Transmitter length DIGITAL CONTROL, INC...
  • Page 96 All numbers are based on math only and do not take into account extremely soft or extremely hard soil conditions, which may cause depth values to vary. 10 FT (3 M) ROD DEPTH CHANGE BASED ON PITCH Depth Increase in Inches (cm) DIGITAL CONTROL, INC...
  • Page 97 All numbers are based on math only and do not take into account extremely soft or extremely hard soil conditions, which may cause depth values to vary. DEPTH INCREASE IN INCHES (CM) PER 15 FT (4.6 M) ROD Depth Increase in Inches (cm) DIGITAL CONTROL, INC...
  • Page 98 75–250 psi is 5 psi Resolution after selecting Transmitter pairing request 0.1% / 100% (Full Scale Sensitive Pitch, FSSP) for a compatible Falcon F5 or F5+transmitter: from 0–50 psi is 5 psi from 50–150 psi is 10 psi DIGITAL CONTROL, INC...
  • Page 99 Some videos are only available in English. If needed, please turn on subtitles and automatic translations. STEP 2 OF 6 Watch video on YouTube: Introducing the Falcon F5+ (1:20 min) https://youtu.be/2ssHHuhS_ew STEP 3 OF 6 Watch video on YouTube: Falcon F5+ Features and Benefits (4:41 min) DIGITAL CONTROL, INC...
  • Page 100 DigiTrak - Falcon F5 with Sub-K Rebar transmitter animated demonstration (2:19 min) https://youtu.be/RbPYhgAJ4z8 STEP 5 OF 6 Watch video on YouTube: Scan, Pick, Pair (1:52 min) https://youtu.be/pTEpehZ09A4 STEP 6 OF 6 Watch video on YouTube: Calibrate Your DCI Transmitter and Locator (1:52 min) https://www.youtube.com/watch?v=j2c6FvpAa6k GLOSSARY DEFINITIONS DIGITAL CONTROL, INC...
