DIGITRAK FALCON F1 SINGLEBAND
USER MANUAL
DCI DigiGuide
05.18.2024

MENU NAVIGATION

Use the trigger switch under the handle of your Falcon F1/F2 to navigate the
menu system and select options.
Click to open the Main menu and move between options.
Hold briefly and release to make a selection.
Hold while over the Locate Line (LL) for a depth reading.
Do nothing in a menu for five seconds to return to the Locate Mode screen.
SCREEN ELEMENTS OVERVIEW
The Locate Mode, Depth, and Predicted Depth screens are the primary
screens you will use for locating.
When the locator is detecting a signal from a transmitter, the Locate Mode
screen provides real-time data about the transmitter's location, temperature,
pitch, roll, and signal strength.
Depth data appears when the trigger is held at the Locate Line (LL) and
predicted depth appears when held at the Front Locate Point.
10
DIGITAL CONTROL, INC
