Select Disable Target
Steering.
GLOSSARY DEFINITIONS
*TARGET DEPTH
A value programmed into the locator, so it can be positioned ahead of the transmitter
housing and used as a steering target. The value programmed should be the desired
depth of the transmitter when it reaches the point below the locator. If a locator is
placed above ground level, such as to provide separation from interference, that height
must be added to the target depth.
Note: If using a Falcon Compact Display, only left/right steering information is available.
The locator used with the Falcon Compact Display must still have a target depth set.
This target depth can be any value.
GET TRANSMITTER INFO
STEP 1 OF 5
From the Main menu, select
Transmitter selection.
STEP 2 OF 5
Align the transmitter so its IR port is near and facing the round IR port on the
front of the locator.
