Model Conversion Instructions
3-33-4 MOVE BIT: MOVBC(568)
Purpose
Ladder Symbol
Variations
Applicable Program Areas
Operands
Operand Specifications
Transfers the specified bit.
MOVBC(568)
S
C
D
Variations Executed Each Cycle for ON Condition
Executed Once for Upward Differentiation
Executed Once for Downward Differentiation Not supported
Immediate Refreshing Specification
Block program areas
OK OK
C: Control Word
The rightmost two digits of C indicate which bit of S is the source bit and the
leftmost two digits of C indicate which bit of D is the destination bit.
15 8 7
C
m
Destination bit: 00 to 15
(Two-digit BCD)
Area
CIO Area
Work Area
Holding Bit Area
Auxiliary Bit Area
Timer Area
Counter Area
DM Area
Indirect DM addresses
in binary
Indirect DM addresses
in BCD
Constants
Data Registers
S: Source word or data
C: Control word
D: Destination word
Step program areas Subroutines
OK
0
n
Source bit: 00 to 15
(Two-digit BCD)
S
CIO 0 to CIO 6143
W0 to W511
H0 to H511
A0 to A959
T0000 to T4095
C0000 to C4095
D0 to D32767
@ D0 to @ D32767
*D0 to *D32767
#0000 to #FFFF Specified values
(binary) only
DR0 to DR15
Section 3-33
MOVBC(568)
@MOVBC(568)
Not supported
Interrupt tasks
OK
C D
A448 to A959
---
