IPC920 Series User's Manual
Install flexible windows cover to
chassis, then fasten all screws.
The installation is complete
2.6
Installing USB dongle
The IPC920 provides an internal USB2.0 type A connector. The procedure of installing the USB dongle into
system is instructed below.
Step 1
Turn off the system.
Step 2
Disconnect the power connector.
Step 3
Loosen the system cover screw and remove the cover from the chassis.
Step 4
Insert USB dongle into connector, then close the system cover back to the chassis
and fasten all screws. Installation is complete.
34
Attach the flexible window cover to the main chassis. Then,
insert and secure the expansion box into the main chassis
using screws. Fasten four screws to fix the cover.
installation is complete.
→
Hardware Installation
The
