IPC920 Series User's Manual
Vibration
Shock
Dimensions
Note:
Note: Please fix the system power input in 24Vdc when plugging an add-on card.
Note: The maximum power rating for expansion slots at 70℃ cannot exceed the following
The maximum loading of +3.3V+5V+12V<150W (EIO110-B)
Note:
Note: The system power rating may thus be changed based on differing combinations
4
IPC920-H-F1, IPC920-R-F1: IEC 60068-2-64 (with SSD: 3Grms STD,
random, 5 to 500 Hz, 1 hr/axis)
IPC920-H-F1E, IPC920-R-F1E: IEC 60068-6-4 (W/SSD: 1Grms STD,
random, 5-500 Hz, 1 hr/axis)
IEC 60068-2-27 (with SSD: 50G, half sine, 11 ms duration)
IPC920-H-E, IPC920-R-E: 83.5 x 192 x 230 mm
IPC920-H-F1E, IPC920-R-F1E: 118.5 x 192 x 230 mm
Since Gen. 2 SSD with JMicron controller has a compatibility issue with Intel
PCH, it is strongly recommended to use Gen. 3 SSD on system.
value:
12V maximum loading for 2 x 8-pin connectors (ATX2-3) are 120W. (EIO110-B)
ofattached devices.
