Step 4
Attach the cable holder (2) to the I/O cable(s) and thread the cable tie (1) through the
holder. (as shown in the illustration below in red rectangle)
Step 5
Open the latch (A) of cable holder and thread cable holder (B) through the latch (as shown
below in read rectangle), tighten the cable holder to encircle the I/O cable(s). The
installation is completed.
Hardware Installation
IPC920 Series User's Manual
→
41
