Step 5 Remove the antenna plug from the top of back cover, an d then install the
antenna on the antenna connector. The installation is complete.
Note:Please use the supplied extended bracket when using a half-size Mini card.
2.6

Installing USB dongle kit

Step 1 Turn off the system.
Step 2 Disconnect the power connector.
Step 3 Loosen screws to remove the heatsink cover from the chassis.
Step 4 Complete the USB dongle kit as the below procedure illustrates.
Hardware Installation

IPC974 Series User's Manual

49
