AXIOMTEK ICO110 User Manual

Robust din-rail fanless embedded system

Hide thumbs

Table Of Contents

Quick Links

Download this manual

ICO110-N3350-AC

ICO110-N3350-AW

Robust Din-rail Fanless

Embedded System

User's Manual

Table of Contents

Need help?

Do you have a question about the ICO110 and is the answer not in the manual?

Questions and answers

Summary of Contents for AXIOMTEK ICO110

Page 1 ICO110-N3350-AC ICO110-N3350-AW Robust Din-rail Fanless Embedded System User’s Manual...
Page 2 Axiomtek does not make any commitment to update the information in this manual. Axiomtek reserves the right to change or revise this document and/or product at any time without notice. No part of this document may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of Axiomtek Co., Ltd.
Page 3: Safety Precautions
Safety Precautions Before getting started, please read the following important safety precautions. The ICO110-N3350 does not come equipped with an operating system. An operating system must be loaded first before installing any software into the computer. Be sure to ground yourself to prevent static charge when installing the internal components.
Page 4: General Cleaning Tips
When use with desk top Class I power adapter, the Power Cord only shall only connect to a socket-outlet with earthing connection. Classification Degree of production against electric shock: not classified Degree of protection against the ingress of water: IP30 Equipment is not suitable for use in the presence of a flammable anesthetic mixture with air or with oxygen or nitrous oxide.
Page 5: Cleaning Tools
Cleaning Tools Although many companies have created products to help improve the process of cleaning your computer and peripherals, users can also use household items to clean their computers and peripherals. Below is a list of items you may need or want to use while cleaning your computer or computer peripherals.
Page 6: Scrap Computer Recycling
If the computer equipment needs maintenance or are beyond repair, we strongly recommended that you should inform your Axiomtek distributor as soon as possible for the suitable solution. For the computers that are no longer useful or no longer working well, please contact your Axiomtek distributor for recycling and we will make the proper arrangement.
Page 7: Table Of Contents
System Block diagram ..............1 1.2.8 Placement ................... 1 Connectors ................. 2 1.2.9 1.2.10 Power ..................2 1.2.11 COM: ICO110-N3350 ..............3 1.2.12 Watchdog Timer (WDT) ............3 1.2.13 Restore BIOS Optimal Defaults (Clear CMOS) ......3 1.2.14 System LED ................3 1.2.15 Operation Temperature..............
Page 8 This page is intentionally left blank. viii...
Page 9: Section 1 Introduction
ICO110-N3350 features an extra-low power consumption Intel® Celeron® N3350(1.1GHz/2-cores) processor supporting an industrial temperature range of-40℃ to +70 ℃. Its front accessible I/O cabling is very convenient for wiring and maintenance. ICO110- N3350 offers an HDMI output, making it particularly well-suited for communication control, SCADA and industrial automation.
Page 10: System Specifications
Din-rail mounting ⚫ Passed CE, FCC, UL, UKCA certification ⚫ O.S. Supported ® ICO110-N3350 supports Windows10 and Linux package. For storage device, ICO110- N3350 supports one mSATA. System Specifications 1.2.1 ⚫ Onboard Intel ® Celeron® N3350 (2-core, 1.1 GHz) processor.
Page 11: System Block Diagram
ICO110-3350 Series User’s Manual 1.2.7 System Block diagram 1.2.8 Placement Introduction...
Page 12: Connectors
ICO110-3350 Series User’s Manual Connectors 1.2.9 PSB529 Connectors Label 2 pin terminal block for Power Input COM Port with RS232 / RS422 /RS485 Battery Connector BAT1 DDR3 SODIMM Socket DIMM1 HDMI output Connector USB3.1 *4 Connector CN2/CN3 LAN connector CN2/CN3...
Page 13: Com: Ico110-N3350
ICO110-3350 Series User’s Manual 1.2.11 COM: ICO110-N3350 ⚫ Front side DB9 supports RS-232/422/485 which can be selected by BIOS. ⚫ Supports Auto Flow Control in RS485 mode. ⚫ Serial Port Pin Assignment: (DB9 Male) as below ⚫ Supports High-Speed Mode 115.2 Kbps, up to 1.5...
Page 14: Operation Temperature
ICO110-N3350-AC = 0.436 kg ⚫ ICO110-N3350-AW = 0.471 kg - 1.2.19 Dimensions ICO110-N3350-AC = 100mm (3.93”) (W) x100mm (3.93”) (D) x48mm (1.88”) (H) ⚫ ICO110-N3350-AW = 100mm (3.93”) (W) x100mm (3.93”) (D) x48mm (1.88”) (H) ⚫ 1.2.20 System I/O Outlets ⚫...
Page 15: Dimensions
ICO110-3350 Series User’s Manual Dimensions The following diagrams show you the dimensions and outlines of the ICO110-N3350. Introduction...
Page 16: I/O Outlets
ICO110-3350 Series User’s Manual I/O Outlets The following figures show you I/O outlets from the front view and top view of the ICO110- N3350. Introduction...
Page 17: Section 2 Hardware Installation
ICO110-3350 Series User’s Manual SECTION 2 HARDWARE INSTALLATION The ICO110-N3350 is convenient for your various hardware configurations, such as Memory Module and mSATA. Chapter 2 will show you how to install the hardware. It includes: Installing the Memory Module ICO110-N3350 Step 1 Turn off the system.
Page 18 ICO110-3350 Series User’s Manual Hardware Installation...
Page 19 ICO110-3350 Series User’s Manual Step 3 Use two fingers to hold the memory module and insert the gold figure into the slot and push the module down. Step 4 The memory module is locked by two latches on the sides. We strongly recommend using “LDC737”...
Page 20: Installing The Msata
ICO110-3350 Series User’s Manual Step 6 Install DDR Bracket Upper limit latch Tighten the screw tightly For ICO110-N3350-AW Step 7 Put the cover back to the system and tighten the screws then close the chassis. Installing the mSATA Step 1 Turn off the system.
Page 21 ICO110-3350 Series User’s Manual Hardware Installation...
Page 22 ICO110-3350 Series User’s Manual Insert the mSATA into the slot which marking with “mSATA ”. Step 3 Hardware Installation...
Page 23 ICO110-3350 Series User’s Manual Step 4 Tighten the screw tightly. Step 5 Put the cover back to the system and tighten the screws then close the chassis. Hardware Installation...
Page 24: Installing Din-Rail Mounting
ICO110-3350 Series User’s Manual Installing Din-rail Mounting The ICO110-N3350 provides Din-rail Mount as below: Step 1 Prepare Din-rail Mount assembling components (screws and bracket). Step 2 Assemble the bracket to the system and tighten the screws. Hardware Installation...
Page 25: Section 3 Ami Uefi Bios Utility
ICO110-3350 Series User’s Manual SECTION 3 AMI UEFI BIOS UTILITY The AMI UEFI BIOS provides users with a built-in Setup program to modify basic system configuration. All configured parameters are stored in a flash-backed-up to save the Setup information whenever the power is turned off...
Page 26: Advanced Features
ICO110-3350 Series User’s Manual <second>. The time is calculated based on the 24-hour military-time clock. For example, 1 p.m. is 13:00:00. Advanced Features This Advanced section allows users to configure and improve your system, or to set up some system features according to your preference. You can select any of the items in the left frame...
Page 27 ICO110-3350 Series User’s Manual CPU Configuration Scroll to this item and press <Enter> to view the CPU Configuration information. (Please refer to the graphics below.) AMI UEFI BIOS Utility...
Page 28 ICO110-3350 Series User’s Manual USB Configuration Scroll to this item and press <Enter> to view the USB Configuration information. (Please refer to the graphics below.) Mass Storage Devices Mass storage device emulation type. “AUTO” enumerates devices according to their media format.
Page 29 ICO110-3350 Series User’s Manual H/W Monitor Scroll to this item and press <Enter> to view the monitor hardware status. (Please refer to the graphics below.) AMI UEFI BIOS Utility...
Page 30 ICO110-3350 Series User’s Manual Trusted Computing This screen provides the function for specifying the TPM settings. Security Device Support Use this item to enable or disable control TPM function. AMI UEFI BIOS Utility...
Page 31 ICO110-3350 Series User’s Manual AMI UEFI BIOS Utility...
Page 32 ICO110-3350 Series User’s Manual SATA Configuration Scroll to this item and press <Enter> to view the SATA Configuration information. (Please refer to the graphics below.) AMI UEFI BIOS Utility...
Page 33 ICO110-3350 Series User’s Manual F81804 Super IO Configuration The default setting for the Serial Port is RS232. You can change the setting by selecting the value you want in each COM Port Type. The COM supports RS422 & RS485 mode and high-speed mode.
Page 34 ICO110-3350 Series User’s Manual AMI UEFI BIOS Utility...
Page 35 ICO110-3350 Series User’s Manual Serial Port Console Redirection The default setting for the console redirection function is [Disabled] (Please refer to the graphics below.) AMI UEFI BIOS Utility...
Page 36 ICO110-3350 Series User’s Manual And you can further change the setting by selecting or setting the value you want in each function as the following pictures. AMI UEFI BIOS Utility...
Page 37: Chipset Feature
ICO110-3350 Series User’s Manual Chipset Feature The Chipset menu allows users to change the advanced chipset settings. You can select any of the items in the left frame of the screen to go to the sub menus： North Bridge ⚫...
Page 38 ICO110-3350 Series User’s Manual AMI UEFI BIOS Utility...
Page 39 ICO110-3350 Series User’s Manual South Bridge ⚫ AMI UEFI BIOS Utility...
Page 40: Security Menu
ICO110-3350 Series User’s Manual Menu Security The default setting for Administrator Password is “Not setting passwords”. The Security menu allows users to change the security settings for the system. You can set the password for both Administrator Password and the User Password.
Page 41: Boot Menu
ICO110-3350 Series User’s Manual Boot Menu Boot has UEFI,Legacy,Compatible mode for selection. The default setting boot mode is [UEFI Mode] The default setting Launch UEFI PXE OpROM policy is [Disable] (Please refer to the graphics below.) AMI UEFI BIOS Utility...
Page 42 ICO110-3350 Series User’s Manual The Boot Option Priorities can select by Boot Option #1, #2…, If the user is using a USB Device. (Please refer to the graphics below.) AMI UEFI BIOS Utility...
Page 43: Save & Exit
ICO110-3350 Series User’s Manual Save & Exit This section allows you to determine whether or not to accept your modifications. Type “Y” to quit the setup utility and save all changes. Type “N” to bring you back to the Previous Setup utility.
Page 44 ICO110-3350 Series User’s Manua This page is intentionally left blank. AMI UEFI BIOS Utility...
Page 45: Appendix Awatchdog Timer
ICO110-3350 Series User’s Manual APPENDIX A WATCHDOG TIMER About Watchdog Timer After the system stops working for a while, it can be auto-reset by the watchdog timer. The integrated watchdog timer can be set up in the system reset mode by program.
