- Page 1 EinScan Pro 2X & HD Series User Manual V3.7.1 EinScan Pro 2X & HD Series_User Manual_V3.7.0...
-
Page 2: Foreword
The user manual (hereinafter referred to as "the Manual") introduces the functions, installation, usage and maintenance of the EinScan Pro 2X & HD Series (hereinafter referred to as "the Scanner") and the EXScan Pro software (hereinafter referred to as "EXScan Pro"). - Page 3 Disputes arising from the Manual and/or related products thereof shall be governed by the laws of the People’s Republic of China. If you have any ambiguity or suggestion about the contents of the Manual, please contact us by the contact information provided in the Manual. EinScan Pro 2X & HD Series_User Manual_V3.7.1...
-
Page 4: Table Of Contents
2X P EP) ... 43 ANDHELD LUS AND 6.2.1 Create a Project ......................43 6.2.2 Scan .......................... 45 6.3 H HD S 2X 2020/E HD) ........ 45 ANDHELD 6.3.1 Create a Project ......................45 EinScan Pro 2X & HD Series_User Manual_V3.7.1... - Page 5 OLOR 7.1.1 Calibration ........................ 71 7.1.2 Fixed Scan Mode ....................... 72 7.1.3 Handheld HD Scan Mode (For EinScan Pro 2X Plus 2020/EinScan Pro 2X 2020/EinScan Pro HD) ......................73 7.1.4 Handheld Rapid Scan Mode ..................75 7.1.5 Post Processing ......................79 7.1.6 Best Practice ......................
- Page 6 ....................... 110 HIRD PARTY OFTWARE 10.5. M ......................... 111 ODEL REVIEW ..........................112 ONTACT SHINING 3D OFFICES: ......................112 APAC REGION & HEADQUARTERS ..................112 EMEA REGION ........................112 AMERICAS REGION ......................112 EinScan Pro 2X & HD Series_User Manual_V3.7.1...
-
Page 7: Product Introduction
3D scanning technology accessible to either professional users or new users. The modular design provides a professional, yet still easy to use 3D digitizing solution for versatile applications. EXScan Pro is a high-performance 3D scanning software, allowing users a faster experience during scanning and data processing. EinScan Pro 2X & HD Series_User Manual_V3.7.1... -
Page 8: Notes
Calibration board Calibration board bracket Markers Phone screen mount Cable clip Markers remover SolidEdge License Card 2.1 Buttons Serial number +/- buttons USB port for add-ons Play button (output voltage and current: 12V/500mA) EinScan Pro 2X & HD Series_User Manual_V3.7.1... -
Page 9: Connection
If the drivers are not installed properly, or the alert “device off-line” keeps coming back. Right- click on the SHINING-CAM and uninstall the driver. Unplug the USB and plug it again, Windows will reinstall the drivers by itself. EinScan Pro 2X & HD Series_User Manual_V3.7.1... -
Page 10: Installation To Add-On
Turn the hook (rotary lever) to the right to lock the camera in position. (3) Power on the scanner and the camera driver will start by itself. Check the device manager to see if the texture camera will show the following. EinScan Pro 2X & HD Series_User Manual_V3.7.1... -
Page 11: Hd Prime
Plug the scanner to the computer then plug in the power cable; the drivers will install automatically. To remove HD Prime, rotate the hook (rotary lever) clockwise before unplug. Check the device manager to see if the Prime will show as the following EinScan Pro 2X & HD Series_User Manual_V3.7.1... -
Page 12: Industrial Pack
After calibration, perform the Accuracy test or click Next to go back to the Mode selection menu. 2.3.3 Industrial Pack Packing List Item Quantity Turntable Tripod Scanner tray (Cradle switch stand) USB cable Power adapter Power cable Installation EinScan Pro 2X & HD Series_User Manual_V3.7.1... - Page 13 Make sure to check the advice for Fixed Mode when using the turntable (see above). Check the Device manager. The turntable will be displayed as below. Device manager with turntable EinScan Pro 2X & HD Series_User Manual_V3.7.1...
-
Page 14: Installation To Einscan Pro
Click “EinScan Software Download” to download the latest version software for EinScan. Step 2: Register using the form. All filed with * must be filled in. Step 3: Download the installer. Save or save as in the desired location on your computer. EinScan Pro 2X & HD Series_User Manual_V3.7.1... -
Page 15: Software Installation
3.3 Software installation Double-click installation package, accept the modification on your computer Choose the installation language, then click OK. Select installation language Follow the instruction on the pop-up window. EinScan Pro 2X & HD Series_User Manual_V3.7.1... - Page 16 You must accept the agreement to install EXScan Pro. Click the Checkbox and click Next to approve the Privacy Notice. EinScan Pro 2X & HD Series_User Manual_V3.7.1...
- Page 17 Choose the default installation path or click the Browse button to select the installation path. Default installation path is recommended. Wait for the installation to be completed. EinScan Pro 2X & HD Series_User Manual_V3.7.1...
- Page 18 Click the Checkbox and click Finish. The software will start automatically When the installation is completed, there will be a shortcut Icon of the software on the desktop. The shortcut in the Start Menu is shown as below: EinScan Pro 2X & HD Series_User Manual_V3.7.1...
-
Page 19: Uninstallation
Or go to Control Panel > Programs > Program and Features, choose EXScan Pro and right- click to uninstall. Follow the instructions step by step. Click Yes to uninstall the software Click OK, then delete the Shining3D folder and its content in (C:). EinScan Pro 2X & HD Series_User Manual_V3.7.1... -
Page 20: Shinning Pass
3.5 Shinning Pass Before getting shining pass, ensure that the device has been connected properly (refer to Connect Cables). EinScan Pro 2X & HD Series_User Manual_V3.7.1... -
Page 21: Registration
To connect device under offline mode, click the reconnect button to re-enter the shining pass interface . Note: After login and entering the operating interface successfully, if the scanner is disconnected, EXScan system would enter the offline mode automatically. EinScan Pro 2X & HD Series_User Manual_V3.7.1... -
Page 22: Activation
If the activation fails, just contact us through the mailbox (EinScan_support@shining3d.com). Send us the serial number of your device through mail and we will try the best to make the things right for you. EinScan Pro 2X & HD Series_User Manual_V3.7.1... -
Page 23: Firmware Upgrade
Click “Upgrade”, software will close automatically, and firmware upgrade program will start. Firmware upgrade program Click “Upgrade”, wait around 1 minute, the firmware starts to upgrade. Waiting to upgrade firmware Do NOT disconnect the scanner, or unplug the power during the upgrade EinScan Pro 2X & HD Series_User Manual_V3.7.1... - Page 24 Firmware Upgrading Complete If the upgrading is failed, recovery will run. Recovering from a failed upgrade Recovery is successful. Please restart the software to upgrade the firmware. EinScan Pro 2X & HD Series_User Manual_V3.7.1...
- Page 25 A successful recovery If recovery fails, turn off the power of the scanner and reconnect the scanner to restart the software for upgrading. A failed recovery EinScan Pro 2X & HD Series_User Manual_V3.7.1...
-
Page 26: Interface And Parameters
When the device is offline, meaning the scanner is not connected to PC, please check the connection and click on the refresh connection button to reconnect. Device offline or connection loose Refresh the connection on the status EinScan Pro 2X & HD Series_User Manual_V3.7.1... -
Page 27: Settings
Click the settings logo from the upper right to open the drop-down menu. Drop down menu Feedback If you have any questions or suggestions, please share with us by clicking “Feedback”. Please leave your email in “My E-mail”. Feedback window EinScan Pro 2X & HD Series_User Manual_V3.7.1... -
Page 28: Einscan Community
User Community refers to the platform for EinScan users to validate the warranty and submit support ticket when necessary. Service live software updates, manual, video download can be accessed in user community. Register your EinScan at community.shining3d.com. EinScan Pro 2X & HD Series_User Manual_V3.7.1... -
Page 29: Help Mode
It opens S3D_teamviewer.exe, for online customer support access or display to another screen or portable screen. Share your ID and password to allow our technicians to remote control of your computer during online technical support. EinScan Pro 2X & HD Series_User Manual_V3.7.1... -
Page 30: Alerts
For activation failure, make sure the scanner is well connected. Redo the activation. Device fails to activate Incorrect configuration Try another USB port and update your graphics card drivers and restart the software. Graphics card incompatible USB not 3.0 EinScan Pro 2X & HD Series_User Manual_V3.7.1... - Page 31 Unavailable Scan Mode Add-on is required for this function EinScan Pro 2X & HD Series_User Manual_V3.7.1...
-
Page 32: Workflow
3.8 Workflow EinScan Pro 2X & HD Series_User Manual_V3.7.1... -
Page 33: Calibration
Clean with clear water only, do not use alcohol or chemical liquid to clean the calibration board. 4.2 Calibration Scan on the front side of the board (black surface with white circles) for calibration. EinScan Pro 2X & HD Series_User Manual_V3.7.1... - Page 34 During calibration, keep the scanner vertical, not parallel to the calibration board. Do not move the board during the capture. When pictures of one position are well collected, the software will turn to the next position with buzzer as below: EinScan Pro 2X & HD Series_User Manual_V3.7.1...
- Page 35 Or it will go back to the scan mode selection interface if there is no other calibration required. Camera calibration result If calibration fails, click Redo calibration to start the same calibration again from the EinScan Pro 2X & HD Series_User Manual_V3.7.1...
-
Page 36: Hd Calibration (Only For Einscan Pro 2X)
Click Next to perform HD calibration or white balance as the software indicates. Or it will go back to the scan mode selection interface if there is no other calibration required. 4.3 HD Calibration (Only for EinScan Pro 2X) On the back side (white) of the calibration board follow the instructions on the video and on the screen to capture the different position. - Page 37 How it works: The software calculates point position and compares it to the known value. The deviation is displayed as result. If the result is more than 0.05mm (accuracy for handheld mode), redo the calibration, and test again. Click Next to enter the Scan Mode interface. EinScan Pro 2X & HD Series_User Manual_V3.7.1...
-
Page 38: Scanned Objects
5. Scanned Objects 5.1 Requirements EinScan Pro 2X series can scan objects from 30*30*30mm ^3 to 4m length. We do not recommend scanning: moving or vibrating objects, which cause the shape of object changed during scanning process. lattice structures with many small deep holes. -
Page 39: Scan Mode
Scan Mode Support Align Mode Feature/Marker/Turntable Coded Fix Scan Targets(With Industrial pack) Feature(2X Plus with Prime 2X/2X Plus Pack)/Marker Handheld HD Scan Feature/Marker/Hybrid/Texture(With 2X 2020/Pro HD Color Pack) Feature/Marker/Hybrid/Texture(With Handheld Rapid Scan Color Pack) EinScan Pro 2X & HD Series_User Manual_V3.7.1... -
Page 40: Scan
Documents or Desktop (desktop by default). Create a folder, click to select it and click New. Then select from Texture Scan and Non-texture Scan. Texture scan is available only when color pack is attached to the scanner. Create or open a project EinScan Pro 2X & HD Series_User Manual_V3.7.1... - Page 41 In the camera window, if the cross is to the left of the red rectangle, it means that the distance is too close. Otherwise, the distance is too far. With proper distance, the cross is in the red box. EinScan Pro 2X & HD Series_User Manual_V3.7.1...
- Page 42 Scanning diagram Step 3 Scanning interface introduction. Scanning interface Right-click on the camera window to display the right camera window. You will see the parts shown in the EinScan Pro 2X & HD Series_User Manual_V3.7.1...
-
Page 43: Scan
Click or press the Space key to start scanning. Click to pause the scanning and click again to resume. When the scan is completed, the data is automatically saved in the project file. Ensure the relative position EinScan Pro 2X & HD Series_User Manual_V3.7.1... -
Page 44: Handheld Hd Mode (For Einscan Pro 2X, Einscan Pro 2X Plus And Einscan Pro Ep)
For EinScan Pro 2X, 400 mm is proper. 300 mm is the closest distance and 500 mm is the farthest distance. For EinScan Pro 2X plus and EinScan Pro EP, 510 mm is proper. 410 mm is the closest distance and 610 mm is the farthest distance. - Page 45 Step 5 Prescan an object. 1) Face the Scanner to the object, press on the interface or on the Scanner to start prescanning. It shows data for preview, but not record the data. EinScan Pro 2X & HD Series_User Manual_V3.7.1...
-
Page 46: Scan
6.2.2 Scan See 6.1.2 Scan. 6.3 Handheld HD Scan Mode (For EinScan Pro 2X 2020/EinScan Pro HD) HD mode means the hand-held scan mode with high resolution and high accuracy. When the operator holds the scanner in hand and moves around the object, the data is instantaneously captured and matched with previously captured data. -
Page 47: Alignment Conditions
The surface of the object requires markers. When the scan starts the markers are required, otherwise “Track lost” will be displayed. At least 4 markers captured previously need to be seen by the scanner in each current scanning frame to be EinScan Pro 2X & HD Series_User Manual_V3.7.1... -
Page 48: Choose Operation Mode
And it is not suggested to use markers under this scan mode, as the density of the markers shall be high, which will result in lots of markers holes on the scan result. The pictures below are the data comparison of normal and high detail: Classic High detail EinScan Pro 2X & HD Series_User Manual_V3.7.1... -
Page 49: Resolution
Hold the scanner to face the object (there must be enough markers on the surface), press the Play button or click Preview to run into Preview mode. In this mode, it will start to show data for preview, but not record this data. EinScan Pro 2X & HD Series_User Manual_V3.7.1... - Page 50 To access preview mode on a current project, reopen it. Scan Distance The rangefinder on the left side reveals different colors based on the distance between the scanner and the EinScan Pro 2X & HD Series_User Manual_V3.7.1...
- Page 51 Closer limit (mm) Optimal distance (mm) 510 Upper limit (mm) Too Close Good Too Far Start Scan Start/Restart scan press Press the Play button or click Start in software to start scanning and recording data. EinScan Pro 2X & HD Series_User Manual_V3.7.1...
-
Page 52: Alignment
You need to go back to any previously scanned area to recover the tracking again and continue scanning. Track lost alert The software will prevent from misalignment when scanning featureless surfaces EinScan Pro 2X & HD Series_User Manual_V3.7.1... - Page 53 If the position tracking fails, “Track lost” alert will appear, meaning you need to go back to an area with previously recorded markers to recover the tracking again and continue scan. Track lost alert Note: If you have imported a global marker file, new markers cannot be added during the scan. EinScan Pro 2X & HD Series_User Manual_V3.7.1...
-
Page 54: Pause Menu
Press the Play button or click Start in the software to continue the scan, Click Stop to generate a point cloud: an optimized 3D point cloud will be generated. Or you may select data to use the Edit tools. EinScan Pro 2X & HD Series_User Manual_V3.7.1... -
Page 55: Optimize Point Clouds
2 opposite faces, markers should be registered following a closed loop to allow re-positioning. 6.3.11 Clouds Editing See 7.5 for data editing 6.3.12 Projects Manage projects on the project group when the scanned data is saved. Icons EinScan Pro 2X & HD Series_User Manual_V3.7.1... - Page 56 Click the right mouse button on the project in the project tree for various operations. The current project is the last one listed on the project tree and is always the one to be added newly scanned 。 data. Reopening previous project turn current EinScan Pro 2X & HD Series_User Manual_V3.7.1...
- Page 57 Manually align SHIFT + click left mouse button to select at least 3 non-collinear corresponding points in the 3D preview windows for Manual Alignment, as shown below. Ctrl + Z: Cancel last point picked. EinScan Pro 2X & HD Series_User Manual_V3.7.1...
-
Page 58: Handheld Rapid Scan Mode
The mode can be used on objects from 30mm to 4m. Under the mode, you can achieve a large size scan efficiently. In this example, the statue is 1m*1.5m*1.5m. EinScan Pro 2X & HD Series_User Manual_V3.7.1... -
Page 59: Create A Project
Create or open a project group Select project group storage location Step 2 On the New Project interface, select from Texture Scan and Non-texture Scan. To select Texture Scan, attach color pack first. EinScan Pro 2X & HD Series_User Manual_V3.7.1... - Page 60 See the example below. For some parts which are difficult for Feature Alignment, a reminder will show up to suggest you stick markers on the area with limited geometric features. Hybrid Alignment EinScan Pro 2X & HD Series_User Manual_V3.7.1...
- Page 61 LED indicator on the Scanner. For distance bar or for LED indicators: Green: Optimal. Red: Too close. Blue: Too far. Good Too Far Close EinScan Pro 2X & HD Series_User Manual_V3.7.1...
-
Page 62: Scan
Ensure the relative storage path of scanned data does not change. Data is automatically saved in the set project file. Step 2 Click on the interface or on the Scanner to pause scanning. EinScan Pro 2X & HD Series_User Manual_V3.7.1... - Page 63 Alert of adding markers Here the "flat objects" means areas with few geometric features. If position tracking fails, "Track Lost" alert is displayed. Return to an area with previously recorded markers to recover the tracking. EinScan Pro 2X & HD Series_User Manual_V3.7.1...
- Page 64 Quality Priority If the scanned data is not misaligned during the scan, you can select this option Speed Priority for a faster processing of point cloud data. EinScan Pro 2X & HD Series_User Manual_V3.7.1...
- Page 65 "_1". New project will create a new entry in the project tree and a new project file in the work folder. EinScan Pro 2X & HD Series_User Manual_V3.7.1...
- Page 66 (.rge) into a separated folder without changing the name. Then import the file as a new project in the work. Create a copy of the project files on a new folder EinScan Pro 2X & HD Series_User Manual_V3.7.1...
- Page 67 Step 1 Click to enter the alignment interface. Both auto alignment and manual alignment available. Step 2 Drag and drop single-plate scan, project or project group to the alignment window. EinScan Pro 2X & HD Series_User Manual_V3.7.1...
- Page 68 Manual alignment Press Shift and left-click meanwhile to select at least 3 non-collinear corresponding points in the 3D preview windows. Press Ctrl and Z, or press ESC key: Cancel last selected point. EinScan Pro 2X & HD Series_User Manual_V3.7.1...
-
Page 69: Clouds Editing
You can only undo the most recently deleted data. Apply edit Click the button or space bar to apply the edition, and exit edit mode. Cancel edit Undo all editors, and exit edit mode. Note: Don’t support markers editing. EinScan Pro 2X & HD Series_User Manual_V3.7.1... -
Page 70: Right-Click Context Menu
Fitting Point cloud: Press Shift + left-click to select data, then click the button “Generate plane”. The cut plane will be created by point cloud fitting. The direction of the plane will be EinScan Pro 2X & HD Series_User Manual_V3.7.1... - Page 71 Cutting plane operation is only workable under the current project. Scan with Cutting plane: Only one side from the cutting plane can be scanned. Cutting plane is very useful when a base need to be removed during scanning. EinScan Pro 2X & HD Series_User Manual_V3.7.1...
-
Page 72: Optional) Use Add-On
On the White side of the calibration board, under the same working lighting environment. Click Start or Press Play, move up and down until you find the optimal distance position. Stay still. While LED and white light are projected. EinScan Pro 2X & HD Series_User Manual_V3.7.1... -
Page 73: Fixed Scan Mode
7.1.2 Fixed Scan Mode 7.1.2.1 Scan Create a project and choose “Texture scan”. Non-texture is selected by default, click Apply to continue. Texture/Non-texture scan option Right-click Texture Camera to display the texture camera view. EinScan Pro 2X & HD Series_User Manual_V3.7.1... -
Page 74: Handheld Hd Scan Mode (For Einscan Pro 2X Plus 2020/Einscan Pro 2X 2020/Einscan Pro Hd)
If the texture is misaligned to the data, check that the camera is well placed and locked. And redo the calibration. 7.1.3 Handheld HD Scan Mode (For EinScan Pro 2X Plus 2020/EinScan Pro 2X 2020/EinScan Pro HD) 7.1.3.1 Scan with Texture Create a project and select Texture Scan. - Page 75 PC configuration could not process it. You could change to a computer with higher configuration to process and the project won’t be damaged. EinScan Pro 2X & HD Series_User Manual_V3.7.1...
-
Page 76: Handheld Rapid Scan Mode
An area with texture missing 7.1.4 Handheld Rapid Scan Mode 7.1.4.1 Scan with texture Create a project and choose “Texture scan”. By default, non-texture is selected, Click Apply to continue. EinScan Pro 2X & HD Series_User Manual_V3.7.1... - Page 77 Data and texture are captured from a different angle. In case of sharp edges, texture- data can be misaligned, try to scan from a different angle. 7.1.4.2 Texture Alignment Create a project and choose “Texture scan”. In Mode of Alignment, select Texture. EinScan Pro 2X & HD Series_User Manual_V3.7.1...
- Page 78 Interface during rapid scan mode, texture alignment If the position tracking fails, “Track lost” alert will appear, meaning you need to go back to a scanned area to recover the tracking and continue scan. EinScan Pro 2X & HD Series_User Manual_V3.7.1...
- Page 79 If blue areas appear on the data (usually on the edge of the scan frame), it means the texture information is missing at these areas, do another scan on the same area from a different path. An area with texture missing EinScan Pro 2X & HD Series_User Manual_V3.7.1...
-
Page 80: Post Processing
Example of a watertight model with texture 7.1.5.3 Texture remapping Enter the texture remapping menu. Click the Texture Remapping to display the Texture menu, click again to close the menu. Texture remapping is accessible before saving the data. EinScan Pro 2X & HD Series_User Manual_V3.7.1... - Page 81 3 party software. This option has no effect on the texture itself. Click Apply to continue. TLO option in texture blending EinScan Pro 2X & HD Series_User Manual_V3.7.1...
- Page 82 Recommended for Artistic applications Mesh, Texture scan.obj 3D rendering (separated & Matching scan.jpg Compatibility with most mesh file scan.mtl editing software Low storage Mesh scan.ply Easy texture editing EinScan Pro 2X & HD Series_User Manual_V3.7.1...
-
Page 83: Best Practice
7.2 HD Prime Pack (For EinScan Pro 2X Plus and EinScan Pro EP) Prime (HD Prime pack add-on) is an add-on for EinScan Pro 2X Plus and EinScan Pro EP. It allows Feature alignment under HD mode and improve the speed and allow markers-free scanning experience when the scanned objects have enough geometry. - Page 84 When entering the Prime scan mode Prime IR projector will be ON, the side LED will turn orange. 7.2.1.1 Align Mode Settings for HD Prime mode Marker Alignment: the surface of the object requires markers. When the scan starts the EinScan Pro 2X & HD Series_User Manual_V3.7.1...
- Page 85 When import project, and continue the scan, the scanning resolution and align mode will be in accordance with the previous setting of imported project. Resolution for HD Prime mode Click Apply to validate and enter the Scanning interface. EinScan Pro 2X & HD Series_User Manual_V3.7.1...
-
Page 86: Hd Prime Scan
Preview with or without markers Check the box “Prime camera” to replace the display of the normal camera(s) with Prime camera (s). In this mode, you can: EinScan Pro 2X & HD Series_User Manual_V3.7.1... - Page 87 Changing the exposure adjustment will automatically change both EinScan and Prime exposure. Check or Uncheck the Prime camera box to insure the good setting for both. Too bright Correct Too dark EinScan camera view EinScan Pro 2X & HD Series_User Manual_V3.7.1...
- Page 88 Interface with markers Stick markers on the object in random pattern, avoiding sticking all markers in one line. To check the rules of sticking markers, refer to 4.2 Preparation. EinScan Pro 2X & HD Series_User Manual_V3.7.1...
- Page 89 If the scan freeze and “Track lost” alert appears, it indicates that the scan cannot match the current data. You need to go back to any previously scanned area to recover the track again and continue scan. Track lost alert EinScan Pro 2X & HD Series_User Manual_V3.7.1...
-
Page 90: Industrial Pack
At least 4 common targets need to be recognized between 2 neighboring scans. EinScan Pro 2X & HD Series_User Manual_V3.7.1... - Page 91 An object with simple features like plain, symmetric surface such as a sphere or cylinder is not recommended for this mode. It is better to use markers to facilitate the alignment for an object with few geometry features. EinScan Pro 2X & HD Series_User Manual_V3.7.1...
- Page 92 Markers alignment is used when the scanner cannot see enough coded targets on the turntable for auto alignment. Markers alignment works in a similar way as turntable coded target alignment; the software matches 2 neighboring scans by recognizing at least 4 common markers. EinScan Pro 2X & HD Series_User Manual_V3.7.1...
- Page 93 Global Markers is accessible if a Global Marker File has been loaded during the project creation. EinScan Pro 2X & HD Series_User Manual_V3.7.1...
-
Page 94: Post Processing
The texture capture is separate from the 3d data capture. If the texture has been captured, it will still be displayed on areas where holes are filled in the mesh processing. If the texture is missing, the corresponding mesh data will be in black. EinScan Pro 2X & HD Series_User Manual_V3.7.1... -
Page 95: Mesh Optimization
Situation when You Fill Holes (for Holes Situation when You Don’t Fill Holes Larger Than 10mm) EinScan Pro 2X & HD Series_User Manual_V3.7.1... -
Page 96: Mesh Editing
①Multi view ②Select Visible ③Select Through ④Rectangular ⑤Polygon ⑥Circle ⑦Paint Brush ⑧Select all ⑨Connected domain ⑩Revert ⑪Unselect ⑫Delete ⑬Undo ⑭Apply edit ⑮Cancel edit Select Visible to select data on the front view only EinScan Pro 2X & HD Series_User Manual_V3.7.1... -
Page 97: Texture Adjustment
After simplification, the polygon numbers, file size and level of detail of data will be reduced accordingly. Set the ratio from 1 to 100, the default is 0. The comparison of detail between before simplification and after simplification (at 70% simplify proportion). Simplification menu EinScan Pro 2X & HD Series_User Manual_V3.7.1... -
Page 98: Mesh Optimization
8.5 Mesh Optimization Mesh optimization can optimize the quality of the data. There are 3 ratio options of mesh optimization. Processing time will be different. Below shows the result of 3 different ratios. EinScan Pro 2X & HD Series_User Manual_V3.7.1... -
Page 99: Smooth
It might remove some small details or smooth some sharp edges at the same time. The example of before and after smoothing is shown below. Run 2 times, data will be smoothed twice. Original EinScan Pro 2X & HD Series_User Manual_V3.7.1... -
Page 100: Remove Small Floating Parts
8.8 Auto Hole Filling Input the perimeter of the biggest hole to be filled. Less than 100mm is recommended. This function will fill every hole with a smaller perimeter than the number input. EinScan Pro 2X & HD Series_User Manual_V3.7.1... -
Page 101: Manual Hole Filling
, according to the order of filling holes, from the last hole to cancel hole filling. Ctrl + Z can also cancel hole filling. Click “Confirm” button to apply current setting and exit the manual hole filling. EinScan Pro 2X & HD Series_User Manual_V3.7.1... -
Page 102: Texture Remapping
TLO result is more convenient for texture manual editing. 9. Measurement After meshing, the Measurement menu will be available on the top. Or click Measurement on the navigation bar, and import data. Go to Measurement. EinScan Pro 2X & HD Series_User Manual_V3.7.1... -
Page 103: Create Feature
The line generated is define as point from to point to point. 2 Planes Click on the plane previously created, or select Plane-Plane should it on the dropdown, repeat for the second Intersection created plane. EinScan Pro 2X & HD Series_User Manual_V3.7.1... -
Page 104: Movement
Enter the value in mm and degrees, click Apply to match the data origin to the input coordinate and orientation. The arrows represent the global coordinate system, Red=X+, Green=Y+, Blue=Z+. Click Reset to cancel the transformation to original position. EinScan Pro 2X & HD Series_User Manual_V3.7.1... -
Page 105: 3-2-1 Movement
Prior to 3-2-1 movement, the creation of a plane, line not normal to the plane and point are required. 3-2-1 movement (plane-line-point alignment) aligns the data by deletion of the Degrees of Freedom. The arrows represent the global coordinate system, Red=X+, Green=Y+, Blue=Z+. EinScan Pro 2X & HD Series_User Manual_V3.7.1... -
Page 106: Measuring
This tool calculates the distance between two points belonging to the surface of the data. Click on the data to pick the first and second point, select one of the two points to redo it. EinScan Pro 2X & HD Series_User Manual_V3.7.1... - Page 107 This tool calculates the volume contains in a watertight mesh. It returns the volume in mm^3 and the coordinates of the smallest box, parallel to the global coordinates, containing all the data. Volume menu EinScan Pro 2X & HD Series_User Manual_V3.7.1...
- Page 108 Prior to the calculation make sure the file is watertight (no holes). File not watertight alert EinScan Pro 2X & HD Series_User Manual_V3.7.1...
-
Page 109: Export Data
◆ Low storage Mesh scan.ply ◆ Easy texture editing ◆ Low storage scan.3m ◆ Mesh Compatibility with Microsoft paint3d ◆ Global Marker File Marker EinScan software scan.p3 ◆ position Measurement marker position EinScan Pro 2X & HD Series_User Manual_V3.7.1... -
Page 110: Scale Data
10.3. Share Data Click after mesh to share data to Sketchfab, it will show the dialog as below. A model title, username and user password are required. Register and view the shared model at http://sketchfab.com. EinScan Pro 2X & HD Series_User Manual_V3.7.1... -
Page 111: Third-Party Software
Geomagic ControlX , Verisurf , Einsense Q , Geomagic Design X , Geomagic Essentials and Solid Edge SHINING 3D Edition) first. Then after meshing data, click to export data to the third-party software. EinScan Pro 2X & HD Series_User Manual_V3.7.1... -
Page 112: Model Preview
Fail to load the mesh data Note: To load a OBJ textured file make sure to have the MTL and JPG files with the same name and in the same folder than the OBJ EinScan Pro 2X & HD Series_User Manual_V3.7.1... -
Page 113: Contact Us
