Shining 3D EinScan H User Manual

Hybride 3d scanner
Hide thumbs Also See for EinScan H:

Advertisement

Quick Links

Download this manual
EinScan H
V1.3.0.1
User Manual
© 2024 SHINING 3D, All rights reserved.

Advertisement

loading
Need help?

Need help?

Do you have a question about the EinScan H and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Shining 3D EinScan H

Summary of Contents for Shining 3D EinScan H

  • Page 1 EinScan H V1.3.0.1 User Manual © 2024 SHINING 3D, All rights reserved.
  • Page 2 Table of Contents Overview About the User Manual Symbol Convention Legal Disclaimer Getting Started About the Hardware About the Software Hardware Device Introduction Appearance Components Device Connection Software Software Installation Environmental Requirements Processor OpenGL Software Installation Device Activation Online Activation Offline Activation Software Interface Interface Overview...
  • Page 3 Calibration Calibration Notice Genauigkeitskalibrierung White Balance Quick Calibration Scan Preparation For Portrait Scan For Foot Scan For Special Objects Scan for Thin-wall Objects Scan for Small Objects Scan Interface Interface Overview ① Camera Windows ② Project List and Scan Setting ③...
  • Page 4 Switch Scanning Status Generate Point Clouds Data Editing Data Editing Toolbar Side Function Bar Menu of the Right Mouse Button Shortcut Cutting Plane Create a Cutting Plane Edit the Cutting Plane Projects Alignment Foot Scanning Operation Steps Post Processing Mesh Model Mesh Parameter Mesh Optimization Mesh Generation...
  • Page 5 Third-party Softwares Contact...
  • Page 6 This document is related to your safety, lawful rights and responsibilities. Read it carefully before installing and using the product. SHINING 3D Tech Co., Ltd. (hereinafter referred to as “the Company”) owns complete intellectual property rights for the contents of this document and, without the written consent of the Company, it is not allowed to copy, transmit, publish, reedit, compile or translate any contents of this document for any purpose or in any form.
  • Page 7 This chapter provides an overview guide for the hardware and the software of EinScan H, making it easy for you to find the corresponding instructions. About the Hardware You can learn about the hardware here, including the appearance of the scanner and its cable connection.
  • Page 8 Hardware Device Introduction The EinScan H adopts both LED light and infrared VCSEL as light sources to help you efficiently capture the data of hair and other black objects. Its flashless infrared technology also provides better experience for human eyes.
  • Page 9 Appearance Serial Number Description Working distance indicator Zoom in / Zoom out Brighter / Darker Preview / Scan / Pause USB port Power input Components...
  • Page 10 Device Connection...
  • Page 11 Caution Make sure you are using the supplied power adapter. The steps to connect the device are as follows: 1. Plug USB and DC IN into the bottom of the scanner. 2. Plug the power cable into the connection cable.
  • Page 12 3. Powered on, the upper light board lights up once, and the bottom two light strips remain constant. 4. Plug the other side of connection cable into the USB 3.0 port of the computer. Now you can see our device in your Device Manager. Software...
  • Page 13 Software Installation To use the scanner, you need to install the EXScan H software first (hereinafter referred to as "the Software"). Environmental Requirements Recommended configuration: Configuration Recommendation Operating Window 10 (64-bit) and Window 11 (64-bit). System Processor Intel® Core™ i7-8700 or above. Note Improper computer configuration or hardware issues will cause CPU performance degradation and affect the user experience, it is recommended that you use the...
  • Page 14 OpenGL Please use a NVIDIA1 discrete graphics card for better and smoother scanning experience. Besides, NVIDIA1 discrete graphics card should meet requirements as follows: ● The graphics card should support CUDA 10.2 or above. You can use NVIDIA Control Panel > Help > System information > Components to get the current CUDA version.
  • Page 15 The instruction about using graphics card on two types of device is shown as follows: Use a discrete graphics card on desktop: Connect your monitor to the port of discrete graphics card on the back of your computer, and OS will use the discrete graphics card automatically.
  • Page 16 Note If you are a new user, please register a Shining 3D Passport account first: you can click Register in the pop-up Shining 3D Passport official website window after starting up the software, or click Sign Up in the Please read and then check Privacy Policy and Terms of use.
  • Page 17 V2C file. Note If you are a new user, please register a Shining 3D Passport account first: you can click Register in the pop-up window after starting up the software, or click Sign Up in the Shining 3D Passport official website 4.Copy the V2C file to the computer without network and import the...
  • Page 18 Interface Overview ① Navigation Bar...
  • Page 19 Step Description Device Demonstrate the device status： Display the device name when it is online. Show "offline" when it is offline; or you can click to reconnect manually. Calibration Click calibrate the device to ensure its scanning accuracy. Scan Mode Click to select a scan...
  • Page 20 Support Provide the entrance to check user manuals and start up the Teamviewer (for remote assistance), and submit ticket for technical support. Provide the entrance to login / logout, My Shining 3D account, Official Website and official Facebook account page.
  • Page 21 When a new version of software is released, you will get prompted when launching the software; if the firmware in the software is newer than that in the scanner, you will get prompted as well. Software Upgrade The software will be upgraded for releasing new features, fixing bugs or optimizing its performance, when a new version will be released, and you will be prompted with an Update Reminder when launching the software next time.
  • Page 22 The firmware will be upgraded for fixing bugs or better scanning effects, when a new version will be released, and you will be prompted with a reminder when launching the software next time. Click Yes to upgrade the firmware, as shown in the right figure. 1.
  • Page 23 Icon Description Learn how to quickly use the 3Dconnexion SpaceMouse. Here you can find the manuals for all 3Dconnexion products. Open the settings panel to customize your 3Dconnexion devices. Use the 3Dconnexion Viewer to review 3D models. Supported formats(.stp, .step, .igs, .iges, .obj, .stl, .ply, .jt, .glTF).
  • Page 25 Button Description Color Display It provides visual feedback on the assigned commands.You have the option to adapt the display brightness, switch between text or icons, and change the text size on the LCD in the 3Dconnexion Settings. 3Dconnexion The SpaceMouse Enterprise features twelve additional programmable function buttons. You Keys can personalize commands assigned to the function buttons using the 3Dconnexion Settings.
  • Page 26 Keyboard Shortcut Function Toggle functions between point cloud edit and markers edit (only ⌃ C t r l works in Scan). Toggle functions between select visible and select through (only ⌃ C t r l works in Post-processing). To toggle the method of selecting data. For more, please see Data ⌃...
  • Page 27 Figure Description Tilt cap left/right to rotate the model on its Z axis. Rotate the model on its Y axis. Tilt cap forwards/backwards to tumble the model on its X axis. Zoom the model in and out. Move the model up and down. Move the model left and right.
  • Page 28 With calibration, the scanner parameters are recalculated, which not only ensures the accuracy of the scanner, but also improves the quality of scanning. Specifically, it includes quick calibration, white balance accuracy calibration: Please select accuracy calibration in your initial use, and quick calibration is recommended when recalibration is required. Calibration is required under the following conditions: When the scanner is used for the first time.
  • Page 29 Für die erstmalige Verwendung des aktuellen Geräts, wenn keine Kalibrierungsdaten in der Software vorhanden sind, ist es erforderlich, vor dem Scannen eine Genauigkeitskalibrierung durchzuführen. Bitte folgen Sie der Kalibrierungsanleitung in der Software, um die Genauigkeitskalibrierung durchzuführen; und drehen Sie den Scanner während der Kalibrierung in 5 verschiedene Positionen. Die Schritte für Genauigkeitskalibrierung sind wie gefolgt: 1.Legen Sie das pfeilförmige Positionspapier auf eine ebene Fläche, wobei die Pfeilspitze nach vorne zeigt.
  • Page 30 3.Passen Sie die Position des Scanners gemäß der Abbildung in der Software-Schnittstelle an und stellen Sie sicher, dass er sich in derselben Position befindet. 4.Drücken Sie leicht auf die Rückseite des Scanners, um die Aufnahme zu starten, und ziehen Sie den Scanner dann langsam in Pfeilrichtung der Software-Schnittstelle von nah nach fern.
  • Page 31 7.Überprüfen Sie das Kalibrierungsergebnis; wenn die Meldung "Genauigkeitskalibrierung erfolgreich" erscheint, können Sie auf Weiter klicken, um in den Weißabgleich-Kalibrierungsprozess zu gelangen. Hinweis Wenn die Kalibrierung fehlschlägt, versuchen Sie es bitte erneut. Wenn die Kalibrierung weiterhin fehlschlägt, kontaktieren Sie bitte Ihren Lieferanten oder unser Support-Team. Wenn es sich nicht um die Erstkalibrierung handelt, können Sie direkt mit dem Scannen beginnen, indem Sie auf...
  • Page 32 3.Press gently on the back side of the scanner to start capturing, then slowly move the scanner vertically up to the height of the middle distance bar; during the movement, please adjust the distance between the scanner and the calibration board based on the color changes of distance bars. Caution Do not move the calibration board after capturing images.
  • Page 33 Caution If the calibration fails, please repeat step 2 to step 4. If you still fail to calibrate the scanner, please contact your supplier or our support team. If still not satisfied with the scanned texture data, please do white balance calibration again, or change the ambient light first.
  • Page 34 Note Please place the calibration board according to the orientation shown in the right animated image. 3.Adjust the scanner's position according to the illustration on the software interface and make sure it has the same position. 4.Press gently on the back side of the scanner to start capturing, then slowly pull the scanner in the direction of the arrow shown on the software interface from near to far;...
  • Page 35 Distance indication bars Color Meaning Blank Not calibrated Blue Calibrating Green Calibrated 5.When all distance bars turn green, the software will do the calculation automatically and demonstrates the calibration result; if it prompts "White balance calibration successful", you can click Next to start scanning.
  • Page 36 If the object to be scanned has rich geometric or textural features, the scanning speed and quality can be better guaranteed; On the contrary, if the object to be scanned has fewer geometric or textural features or a high degree of feature repetition, you need to do some preparation work before scanning to enhance your scanning experience.
  • Page 37 For Special Objects Note Not recommend to scan following objects: Soft material object that cannot be hung. Lattice structures with many small deep holes. Moving or shaking objects. Frequent coordinate changes will lead to a poor scanning quality. Object Preparation Notes while scanning Transparent, shiny,...
  • Page 38 It is recommended that you select Global Markers mode and scan with markers: 1.Prepare two auxiliary objects with markers placed on their upper and lateral sides. 2.Place different markers on lateral sides of the scanned object. 3. Place the scanned object side-upright and fixed, and place the auxiliary objects on both sides of the object (at a distance apart).
  • Page 39 4.During the scanning process, the markers on both sides of the auxiliary objects should be scanned to complete the transition between the front and back side, then scan the lateral sides, and scan the left data after removing the auxiliary objects. Scan for Small Objects To scan small objects without distinct features, as shown in the right figure:...
  • Page 40 3.Turn over the object, and click to create a new project within the current project group, and scan the back side of the object. 4.Click align By Feature to align two projects (if not successful, click By Manual instead). Scan Interface Interface Overview Note For the introduction to the top navigation bar and Settings &...
  • Page 41 ① Camera Windows Check the actual scanning scenarios captured by bottom camera and texture camera so as to adjust parameters accurately. Note The window for texture camera is disabled by default and can be enabled through the menu of the right mouse button.
  • Page 42 Note If the program's memory usage is excessively high, it is recommended that you close other non-scanner software and wait patiently. ⑦ Previewing / Scanning Window Windows for viewing the pre-scan results and the scanned model effects. ⑧ Data Editing Toolbar Edit the scanned data and adjust the perspective, for more see data editing.
  • Page 43 Project Group Create or open a project group before scanning. Project group is the standard file structure of the EXScan H, and each project contains the scan data of its own; one project group can contain one project or multiple projects, the introduction of application scenarios is as shown in the table below: Note The "Scenario"...
  • Page 44 In the Scan step interface, click the Project Group button in the right-side function bar. In the pop-up window, click New project group. The following steps are the same as mentioned above. Note The default name for the project group is the content entered during the last creation of the project group, followed by "_1"...
  • Page 45 Additionally, you can also open an individual project within the current project group: In the Scan step interface, click the Open Project Group button in the left Project List panel. In the pop-up file selection dialog, choose a project file by directly clicking or searching, and click "Open". Project Consider each project as a part of the project group.
  • Page 46 (*.p3). Note Each foot station has its own configuration file; please log into Shining 3D Passport official website , choose EinScan-FootPlatform and enter serial number in the window of Bind More Products to complete binding, and download the configuration file in the interface of My Products.
  • Page 47 Resolution Description High 0.2 mm Medium 0.5 mm 2.0 mm Note Foot station alignment mode does not support custom resolution, and the default value is 0.5 mm. With smaller setting value, you will get more details, but it will lead to larger file size and longer processing time, and requires higher computer configuration.
  • Page 48 Portrait Select Mode of Alignment Alignment Description Mode Features Automatic align using the geometric features on the surface of the object to be scanned; suitable for objects with rich geometric features. Texture Automatic align using texture features on the surface of the object to be scanned; suitable for objects with rich color textures.
  • Page 49 Note This function can not be disabled under the Texture alignment mode. Texture switch cannot be changed once the project group has been created. Object Object Size Object Size Description Large objects Object size larger than 300 mm * 300 mm * 300 mm. Medium objects Object size between 100 mm * 100 mm * 100mm and 300 mm * 300 mm * 300 mm.
  • Page 50 Resolution Description High Medium objects: 0.2 mm. Large objects: 0.5 mm. Medium Medium objects: 0.3 mm. Large objects: 1.0 mm. Medium objects: 0.5 mm. Large objects: 2.0 mm. Note With smaller setting value, you will get more details, but it will lead to larger file size and longer processing time, and requires higher computer configuration.
  • Page 51 Preview the real-time image captured by the scanner camera so as to adjust the brightness of the camera accordingly. Scan Mode Hybrid alignment mode (including markers): Click Open global markers file button to import local global markers file. Note If you click Open global markers file button when a global markers file already exists in the current project, you will be prompted with a message "Are you sure to clear current data and rescan?".
  • Page 52 Note Add global markers switch can not be changed during the scanning process. If you click Open global markers file button when a global markers file already exists in the current project, you will be prompted with a message "Are you sure to clear current data and rescan?". If you click Open global markers file button or switch to Scan Global Markers, when there exists point cloud data, you will be prompted with a message "Are you sure to clear current data?".
  • Page 53 Note Foot station alignment mode does not support this function. This function is available only when Texture scan is enabled. This switch cannot be changed during scanning. Plane Detection With this feature being enabled, the software will automatically detect and erase the plane where the object is located.
  • Page 54 To modify the point spacing size for the current single project, you can drag the slider or click the up/down arrow buttons: the default value is set to the point distance when creating a project group. Note If the number of projects in the current project group is greater than 1, this feature is not available. If the adjusted point distance is smaller than the original setting, it is recommended that you should modify the point distance based on the prompts in the pop-up window, or it may result in insufficient memory for generating the mesh model or point cloud.
  • Page 55 It is recommended that you turn on the texture LED light when there is not enough light for better texture scanning. Note This function is available only when Texture scan is enabled. This switch cannot be changed during scanning. Hair Mode Enable this function to scan hair easier, but it could increase data noise.
  • Page 56 Note The unique plane marked during the scanning preview can change in real-time. The plane marked as the last one at the end of the scanning preview will be considered. If the Cutting Plane feature is used, this feature cannot be used. Adjust Point Distance To modify the point spacing size for the current single project, you can drag the slider or click the up/down arrow buttons: the default value is set to the point distance when creating a project group.
  • Page 57 Global Markers alignment mode: Click Open global markers file button to import local global markers file, or directly click Scan Global Markers and optimize global markers. After switching to Scan Point Clouds, you can click Add global markers and new recognized markers can be added to global markers. Note Add global markers switch can not be changed during the scanning process.
  • Page 58 Working Distance According to different object size and alignment requirements, you need to drag the slider to adjust the working distance, namely effective area of the scanner. The range of value is 200 mm ~ 700 mm (200 mm ~ 450 mm for medium objects); higher value means using longer working distance to get more data, but will lose some detail of the data.
  • Page 59 Auto Cutting Plane With this feature being enabled, during the scanning preview, the software will intelligently and in real-time identify the largest plane and mark it with a blue-green grid. The data below the marked plane will not be shown. Note The unique plane marked during the scanning preview can change in real-time.
  • Page 60 Caution When scanning the recessed areas of an object, please hold the scanner directly towards the area to be scanned. Icon Function Description Preview Preview scanning effect. Note In this mode, the scanning data will not be saved and scan parameters can be adjusted according to the scanning effect.
  • Page 61 Note Foot station alignment mode and portrait scan only supports Optimize and Generate Point Cloud. The time it takes to generate point cloud depends on the data size of your project and the hardware configuration of your PC. If necessary editing operations have been performed on the scanned data, please apply the edits before generating the point cloud.
  • Page 62 Icon Function Description Perspective The object appears larger when closer, and smaller when farther away, which View is consistent with the rule of normal human eyes to observe the 3D world. You can click this button to switch to orthogonal view. Orthogonal The object does not appear larger when closer, and smaller when farther View...
  • Page 63 Icon Function Description Point Cloud In this mode, a point cloud is chosen. Click it again and you can switch to the Edit Edit Markers mode.(This mode is enabled by default if there is a point cloud.) Note After switching to this mode, the selected markers data (if any) will be retained to facilitate synchronized deletion and other editing operations.
  • Page 64 Icon Function Description Rewind To select (highlighted in red) the scanning data corresponding to a specific frame, drag the progress bar. Click Confirm to delete the corresponding data; click Exit to exit rewind. Note Up to 200 frames of data can be rewound; and you can rewind multiple times until the first frame of this scan.
  • Page 65 Icon Function Description Undo Undo the last deletion and recover the last deleted data. Multiple deletions can be undone by clicking multiple times. Redo Redo the last operation and recover the last operation data. Multiple operations can be redone by clicking multiple times. Cancel Undo all edit, and exit edit mode.
  • Page 66 Icon Function Instruction Generate the Point After completing scanning, generate the point cloud directly. Cloud You can click the button to expand the list to switch functions. Note Foot station alignment mode and portrait scan only supports Optimize and Generate Point Cloud. Optimize &...
  • Page 67 Function Description Select all/Invert/Unselect/Delete The function is the same as the function on editing bar, and can be selected data operated by shortcut keys. Connected Domain Click the button after selecting a patch of data and all connected region to the selected data will be picked;...
  • Page 68 Shortcut Function Press and hold Fit view ⌃ C t r l Scroll wheel Zoom in/zoom out the data Press and hold the and move the cursor Translate the data M i d d l e B u t t o n Press and hold Set Rotate Center ⌃...
  • Page 69 Method Description Fitting Point Cloud Hold to select the point cloud data, and click Create Plane. ⇧ S h i f t L e f t B u t t o n Creating Straight Line Hold to draw a line, and click Create Plane. ⇧...
  • Page 70 Translate the cutting plane: after generating the plane, you can enter numbers in the editing box or drag the arrow of the cutting plane's normal to translate the cutting plane. Rotate the cutting plane: you can drag any of the four small balls on the edges of the cutting plane rotate the cutting plane along a certain direction.
  • Page 71 Alignment Description Note mode 1. Choose By Feature. Objects that have repeatable features (like rounds or rings) or small objects 2. Select the project which needs alignment in are not suitable for this mode. the fixed window and the floated window. By Feature 3.
  • Page 72 Caution It is recommended that you keep the surrounding environment clean and unobstructed before scanning. Please place the feet parallel to the long edge of the glass foot station and do not cover the markers. Please avoid scanning in environments with strong direct light above the foot station, as it may cause overexposure and affect speckle projection.
  • Page 73 Each foot station has its own configuration file; please log into , enter serial Shining 3D Passport official website number in the window of Bind More Products to complete binding, and download the configuration file in the interface of My Products.
  • Page 74 6.After mesh completes, you will be directed to the Post-Processing step for mesh editing. Note If both left and right foot have been scanned, Two Feet model is displayed as default; you can click this button to switch to Left Foot and Right Foot.
  • Page 75 Icon Function Description Unwatertight Unclosed model stays the way it is scanned. Processing time is quicker than Watertight. Half Some of the holes will be filled automatically. watertight Holes with a diameter less than or equal to the resolution*5 will be filled.
  • Page 76 Optimization Description Instructions options Filter Optimize the data and improve the clarity of the data. The higher Setting the filter the level, the less the small details. level high will lose None: No optimization. some small details. Standard (default): Optimizes data slightly and preserves data characteristics.
  • Page 77 Optimization Description Instructions options Simplification Set the triangle number. When the simplification is greater than the maximum 1. When the point distance is triangles, prioritize the simplification. or lower than 0.5 mm, this function is enabled as default and the default value is 40 with a range of 0 to 99.
  • Page 78 Optimization Description Instructions options Remove Spike Remove spike-like data on the image edge. Marker Hole Fill in the surface of the object that For the align mode of Markers, this functions is Filling is not scanned to the pasting enabled by default for unwatertight and semi- marker.
  • Page 79 After meshing model, you can perform mesh editing, data editingand use some other functions. Mesh Editing In the Mesh Editing window on the left side of the interface, click + to unfold the function panel.
  • Page 80 Optimization Description Instructions options Texture Brightness and Contrast can be adjusted. Only project files that exclusively Drag the slider or click the page up/down arrow contain textures are accessible to to set the value from -100 to 100. The default is this function.
  • Page 81 Optimization Description Instructions options Remove Small Remove small floating parts in the scan data. Click to reset the value to Floating Parts Drag the slider or click the page up/down arrow to set default. the ratio from 1 to 100. The default is 0, indicating no Click Preview to preview.
  • Page 82 Optimization Description Instructions options Flip Normal To redefine the front direction of the scanned data in Texture remapping should be reversal design. performed first as it is not Hold to select areas accessible after flip normal. ⇧ S h i f t l e f t m o u s e b u t t o n to be flipped.
  • Page 83 Optimization Description Instructions options Mirror Take the front view plane of scan data as the working Click Preview to preview. plane. Draw a straight line as the central axis and Click Confirm confirm and perform a symmetrical copy. save. This action is Hold to draw a straight ⇧...
  • Page 84 Note If both left and right foot have been scanned, Two Feet model is displayed as default; you can click this button to switch to Left Foot and Right Foot. For the instruction to other editing tools, please see data editing toolbar.
  • Page 85 Icon Function Description Open file Open a file (STL, OBJ, PLY) for post processing. Export Your : Save the scanned data in the specified format (ASC, STL, OBJ, PLY, Scan 3MF) locally. : If you have installed the EXModel software and you are in the post- processing or measurement interface with mesh data, click this button to start up the software and import the data into it.
  • Page 86 Icon Function Description Model After enabling the model display by clicking the icon or pressing , the F 1 2 Display model will rotate at a specified speed (Click to adjust the rotate speed; press again to exit). ⎋ F 1 2 E s c Note The model will only rotate and display from the current view after entering the...
  • Page 87 Note On the Measurement step interface, you can use multi view and other editing tools. On the Measurement step interface, you can operate by right mouse button and shortcuts. Additionally, it also supports clicking button in the right-side function bar to import models (including third- party 3D models).
  • Page 88 Creation Description Note Method Selected Points 1. Click the data to select the point. 2. Click the Create button to create a feature point. Please Select a 1. Click an existing marker to You can select this method to create feature points Marker select the point.
  • Page 89 Creation Description Note Method Point-Point 1. Click the data to select the points. 2. Click the Create button to create a feature line. Note You can tick the checkbox before From or to and re-select the feature points. Marker to 1.
  • Page 90 Creation Description Note Method 3 Points Fit 1. Click the data to select the point. The three points can not be in a line. 2. Click the Create button to create a feature plane. Note You can tick the checkbox before Point1, Point2 or Point3 and re-select the points.
  • Page 91 Creation Description Note Method Marker Point- 1. Click an existing feature line or choose a You can select this method to create Line Fit line in the drop-down list. a feature plane for model data that only have markers and are not 2.
  • Page 92 Input value and adjust coordinates: Input values in Offset or Rotation, and click Move to to align model center with input coordinates and axis direction with rotation value. Adjust coordinates by the object mover tool: Hover the cursor on object mover tool. Once the object mover tool shines, hold Left Mouse Button or Middle Mouse Button to adjust the position and angle of model.
  • Page 93 Plane：Select a feature surface in the drop-down list, and select an axis in corresponding constraint drop- down list. The arrow on the plane corner indicates the positive direction of the plane, and the selected axis direction will be consistent with the plane direction. Line：Select a feature line in the drop-down list, and select an axis in corresponding constraint drop-down list.
  • Page 94 Click Align and move the coordinate frame to the center of the object, with its X-axis perpendicular to the screen, Y-axis parallel to the screen and pointing rightward, and Z-axis parallel to the screen and pointing upward. The object remains its position. Click Move and move the coordinate frame to the bottom center of the object.
  • Page 95 Calculate the distance between two points or markers on the surface of the scanned data. When two points of the data are selected, the distance will show itself with a unit of mm. Click Close to close the front window. Note ●...
  • Page 96 Volume Calculate the volume of Meshed data with a unit of mm³. When you switch to Volume, the volume of the scanned model and the coordinates of corresponding bounding box will show themselves. Click Close to close the front window. Note This function is only available for meshed models.
  • Page 97 Note For the foot station alignment mode, you can choose to save the data of two feet, left foot or right foot, and support multiple choices. Format Data Type Saved as Recommended Application Scenario ASC (whole Optimized cloud Scan.asc Check the data. piece) points Quick export and no need for post-...
  • Page 98 Sketchfab Shining3D Digital Cloud You can upload the encapsulated data to after mesh. On the interface of Post-processing or Measurement step, click in the right-side function bar to upload the encapsulated data to Sketchfab , where the title, username and password are required to be provided. You can log into the website afterwards to view the shared models.
  • Page 99 Email: https://support.einscan.com Support platform: Shining 3D Offices APAC Region & Headquarters SHINING 3D Tech Co., Ltd. Hangzhou, China Phone: +86 571 82999050 Add: No. 1398, Xiangbin Road, Wenyan, Xiaoshan, Hangzhou, Zhejiang, China, 311258 EMEA Region SHINING 3D Technology GmbH.
  • Page 100 Americas Region SHINING 3D Technology Inc. San Leandro, United States Phone: +1415 259 4787 Add: 2450 Alvarado St #7, San Leandro, CA 94577...
