7.4 Installing Components
Table 7-2 Component installation list
Component
Rack mounted fire
extinguishing
system
Battery pack
Rack controller
Smart PCS
(Optional)
Maintenance
socket
(Optional) Smart
Power Sensor
(DDSU666-H)
Before installing components, ensure that the ESS is securely installed.
7.4.1 Installing the Rack Mounted Fire Extinguishing System
Prerequisites
●
●
Procedure
Install the rack mounted fire extinguishing system.
Issue 03 (2023-03-30)
Installation Position
Above the power distribution area in the
ESS
Battery guide rails in the ESS
Right side of the ESS
Left side of the ESS
Power distribution area in the ESS
Power distribution area in the ESS
NO TICE
Ensure that the rack mounted fire extinguishing system is intact.
Before installation, read the documents delivered with the rack mounted fire
extinguishing system to understand the installation requirements and
precautions.
Copyright © Huawei Digital Power Technologies Co., Ltd.
7 Installation
Quantity
1
12
1
1
1
1
84
