No. Cable Hole
Ground cable
1
hole
The position for cutting the pagoda connector is for reference only. The actual cable usage
may vary.
4

Installing Components

• The ESS is not powered on.
• The installation personnel have taken safety protection measures, for example, wearing
insulated gloves and shoes.
4.1
Securing the ESS
Each angle steel bracket must be secured by two mounting holes. It is recommended that the
outer two mounting holes be used. If steel bars in a concrete base block the drill bit or when
the position deviation occurs during the first drilling, use the inner mounting holes.
