7.4 Installing Components

Table 7-2 Component installation list
Component
Rack mounted fire
extinguishing
system
Battery pack
Rack controller
Smart PCS
(Optional)
Maintenance
socket
(Optional) Smart
Power Sensor
(DDSU666-H)
Note [1]:
● Six dummy battery packs are preinstalled in the LUNA2000-97KWH-1H1 ESS,
● Four dummy battery packs are preinstalled in the LUNA2000-129KWH-2H1
● Two dummy battery packs are preinstalled in the LUNA2000-161KWH-2H1
● Twelve battery packs are required in the LUNA2000-200KWH-2H1 ESS.
Before installing components, ensure that the ESS is securely installed.

7.4.1 Installing the Rack Mounted Fire Extinguishing System

Prerequisites
●
●
Issue 10 (2023-11-07)
Installation Position
Above the power distribution area in the
ESS
Battery guide rails in the ESS
Right side of the ESS
Left side of the ESS
Power distribution area in the ESS
Power distribution area in the ESS
in which six battery packs are required.
ESS, in which eight battery packs are required.
ESS, in which ten battery packs are required.
NO TICE
Ensure that the rack mounted fire extinguishing system is intact.
Before installation, read the documents delivered with the rack mounted fire
extinguishing system to understand the installation requirements and
precautions.
