VLT® HVAC Drive FC 131
Programming Guide
Parameter Option/range
–
Parameter 1-29
Automatic Mo-
tor Adaption
(AMA)
0.000–9999.000 Ω
Parameter 1-30
Stator Resist-
ance (Rs)
Parameter 1-37 0.000–1000.000 mH
d-axis Induc-
tance (Ld)
0.000–1000.000 mH
Parameter 1-38
q-axis Induc-
tance (Lq)
2–100
Parameter 1-39
Motor Poles
Parameter 1-40 10–9000 V
Back EMF at
1000 RPM
Parameter 1-42 0–100 m
Motor Cable
Length
0.000–1000.000 mH
Parameter 1-44
d-axis Induc-
tance Sat.
(LdSat)
0.000–1000.000 mH
Parameter 1-45
q-axis Induc-
tance Sat.
(LqSat)
20–200%
Parameter 1-46
Position Detec-
tion Gain
Parameter 1-48 20–200%
Current at Min
Inductance for
d-axis
20–200%
Parameter 1-49
Current at Min
Inductance for
q-axis
22 | Danfoss A/S © 2022.05
Default Usage
Changing this parameter affects the settings of other pa-
rameters.
Performing an AMA optimizes motor performance.
Off
Size related Set the stator resistance value.
Size related Enter the value of the d-axis inductance. Obtain the value
from the permanent magnet motor datasheet.
Size related Enter the value of the q-axis inductance.
Enter the number of motor poles.
4
Size related Line-line RMS back EMF voltage at 1000 RPM.
50 m Enter the motor cable length.
Size related This parameter corresponds to the inductance saturation of
Ld. Ideally, this parameter has the same value as parameter
1-37 d-axis Inductance (Ld). However, if the motor supplier
provides an induction curve, enter the induction value,
which is 200% of the nominal current.
Size related This parameter corresponds to the inductance saturation of
Lq. Ideally, this parameter has the same value as parameter
1-38 q-axis Inductance (Lq). However, if the motor supplier
provides an induction curve, enter the induction value,
which is 200% of the nominal current.
Adjusts the height of the test pulse during position detec-
100%
tion at start.
100% Enter the inductance saturation point.
This parameter specifies the saturation curve of the d- and q-
100%
inductance values. From 20–100% of this parameter, the in-
ductances are linearly approximated due to parameter 1-37
d-axis Inductance (Ld), parameter 1-38 q-axis Inductance (Lq),
parameter 1-44 d-axis Inductance Sat. (LdSat), and parameter
1-45 q-axis Inductance Sat. (LqSat).
Programming
N O T I C E
AU370727746889en-000101 / 130R0994
