Parameter Option/range
Parameter 1-70
[0] Rotor Detection
PM Start Mode
[1] Parking
[3] Rotor Last Position
Parameter 1-73
[0] Disabled
Flying Start
[1] Enabled
Parameter 3-02 -4999.000–4999.000
Minimum Refer-
ence
-4999.000–4999.000
Parameter 3-03
Maximum Ref-
erence
Parameter 3-41 0.01–3600.00 s
Ramp 1 Ramp
Up Time
Parameter 3-42 0.01–3600.00 s
Ramp 1 Ramp
Down Time
Parameter 4-12 0.0–400.0 Hz
Motor Speed
Low Limit [Hz]
0.0–400.0 Hz
Parameter 4-14
Motor Speed
High Limit [Hz]
0.0–400.0 Hz
Parameter 4-19
Max Output
Frequency
Parameter 5-40 See parameter 5-40 Function
Function Relay
Relay.
Parameter 5-40 See parameter 5-40 Function
Function Relay
Relay.
Parameter 6-10 0.00–10.00 V
Terminal 53
Low Voltage
Parameter 6-11 0.00–10.00 V
Terminal 53
High Voltage
0.00–20.00 mA
Parameter 6-12
Terminal 53
Low Current
Danfoss A/S © 2022.05
Default Usage
Select the PM motor start mode.
[1] Parking
[0] Disabled Select [1] Enabled to enable the drive to catch a motor spin-
ning due to mains dropout. Select [0] Disabled if this function
is not required. When this parameter is set to [1] Enabled, pa-
rameter 1-71 Start Delay and parameter 1-72 Start Function are
not functional. Parameter 1-73 Flying Start is active in VVC+
mode only.
0 The minimum reference is the lowest value obtainable by
summing all references.
The maximum reference is the lowest obtainable by sum-
50
ming all references.
Size related If asynchronous motor is selected, the ramp-up time is from
0 to rated parameter 1-23 Motor Frequency. If PM motor is se-
lected, the ramp-up time is from 0 to parameter 1-25 Motor
Nominal Speed.
Size related For asynchronous motors, the ramp-down time is from rated
parameter 1-23 Motor Frequency to 0. For PM motors, the
ramp-down time is from parameter 1-25 Motor Nominal
Speed to 0.
0 Hz Enter the minimum limit for low speed.
Enter the maximum limit for high speed.
100 Hz
100 Hz Enter the maximum output frequency value. If parameter
4-19 Max Output Frequency is set lower than parameter 4-14
Motor Speed High Limit [Hz], parameter 4-14 Motor Speed High
Limit [Hz] is set equal to parameter 4-19 Max Output Frequen-
cy automatically.
[9] Alarm Select the function to control output relay 1.
[5] Drive run- Select the function to control output relay 2.
ning
0.07 V Enter the voltage that corresponds to the low reference val-
ue.
10 V Enter the voltage that corresponds to the high reference val-
ue.
Enter the current that corresponds to the low reference val-
4 mA
