INTRODUCTION

1

OVERVIEW

The ProX DMP200 is a high quality direct metal printing (DMP) machine. It brings reliability and repeatability to production-
®
level direct metal printing. The ProX
quality and low maintenance 3D printing machines.
With direct metal printing, parts are built up layer by layer. Using this technique, the most complex parts can be made.
Loose metal powder particles are melted together by a high-precision laser. The laser is directed to the powder particles
in order to selectively build up thin subsequent horizontal layers. Connecting each new layer to the previous one, it brings
a high quality alternative to the traditional manufacturing processes. Since no tools are used and no material is removed,
waste is reduced significantly. Parts aren't built by removing material in different steps, but by adding material. Other
advantages are the quick set up times and the ability to produce very complex assemblies as a single part.
The ProX DMP200 has a build platform of 140 x 140 x 100mm which can produce high quality parts in a variety of metals.
®
In order to operate the machine safely and efficiently, please follow the following instructions and warnings. The machine
is a Class I Laser System equipped with a Class IV laser that can be potentially dangerous when the machine is operated
differently than stated in this manual.
The principal technical characteristics are mentioned on the table :
Fiber Laser
Layering system
Building volume
Metal materials
Ceramic materials
Repeatability
Detail size
Loading system
Recycling system
CAD/CAM software
Control software
CAD read formats
"Dental" configuration
The ProX® DMP200 system, in its "Dental" configuration, is a solution for the rapid manufacturing by laser sintering to
perform directly, without tools, fixed and removable dental prostheses.
"Dental" configuration includes the exclusive use of Cobalt Chrome Molybdenum alloy powder ST2724G certified as a
medical device in a standard ProX® DMP200 machine associated with
modifiable manufacturing parameters by the user.
In the case of a different use of the conditions defined by the "Dental" configuration - as the use of another powder in the
machine or modification of the manufacturing parameters - the conformity of dental components built with the machine
is not guaranteed by the manufacturer anymore. It will be then the responsibility of the user to qualify the manufactured
dental elements in compliance with standards and regulatory requirements of each country.

CONTROL SOFTWARE VERSION

All figures and features related to the user interface on this user guide correspond to control software from version
V2.1.5.2.
3D SYSTEMS, INC.
DMP200 is designed to meet industrial market demands of reliable, high material
®
P=300 W – λ=1070 nm
Adjustable
140 x 140 x 100 mm
Stainless steel, tool steels, non-ferrous alloys, super alloys...
Alumina, cermet, ...
x=20 µm ; y=20 µm ; z=20 µm
x=100 µm ; y=100 µm ; z=20 µm
Semi-automatic
External option
3DXpert
PX Control V2
STL
ProX DMP Dental
1
CAM software including all non-
