Preparation menu

Preparation Menu
By clicking on the
Click "Validate" to confirm, or "Quit" to cancel.
NOTE: this window will appear only if the machine has finished the
previous preparation . Otherwise, the application will display the
Preparation Assistant
The Preparation Menu allows user to prepare the printer to print a job, and to unload the printed part.
This menu is composed by 8 successive steps. Each step shows manual and automatic actions to be performed, and
consists of :
1
1
List of the preparation steps (green: completed, blue: in progress, grey: not performed)
2
Actions executed during the automatic cycle
3
Button to launch the current cycle
4
List of actions of the current step to be performed by the operator
5
Available commands of the current step
6
Button to navigate to the next step
3D SYSTEMS, INC.
button, the "PX Control : Preparation assistant" window appears.
window at the current step .
35
3
2
4
5
6
