Event browser
The Event browser tool is composed of 4 tabs:
• Version tab
It lists the different software versions and when they have been installed.
• Manufacturing tracking tab
Each event occured during a preparation or a job is traced and stored on a tracking file. Each time a new sintering plate is
loaded into the printer, a tracking file is created. As long as a tracking file is existing on the printer, it can be viewed and
exported.
When the plate is unloaded, its tracking plate file will be closed.
The format of the tracking file is ".xml", and is composed by: PrinterType_SerialNumber_PlateNumber
• Printer type (e.g ProX DMP200)
• Serial number (e.g 1122333)
• Plate number: the number entered during the plate loading (see section "Step 4 : Zero sintering" on page 37) is
linked to the name of the corresponding tracking file
1. Click on the "Open file" button to open a
tracking file (A).
2. Select the desired tracking file from the list.
3. All corresponding events will be indicated on
the information area (B).
4. Optional: use the "Information filter" (C)
to select an event type (Preparation or
Manufacturing).
5. Optional: use the "+" or "-" buttons (D) to
directly open/close all navigation trees.
6. Export functions (E): to export the tracking file
("csv", "xml" or "pdf" formats).
7. The export button (F) creates a manufacturing
report in "pdf" format (see example
"Manufacturing report" on page 51).
3D SYSTEMS, INC.
A
E
F
C
51
D
B
