Manufacturing menu

This menu allows the user to start the manufacturing process (layering and sintering), and also to see the progress. It
consists of three parts.
Consult the section "Start a manufacturing process" on page 64 for details on basic rules of starting a job.
1
Progress area
• Current / Project part height (mm)
• Current / Estimated manufacturing time (hours),
• Manufacturing progress in %,
• Layering : the current number, the duration of
the current layering, and the total layering time,
• Sintering : the current number, the duration of
the current sintering, and the total sintering time.
2
Launching area
• Selection of the Start/End cycles:
Start of cycle: if selected, executes actions of the
•
End of cycle: if selected, executes actions of the
•
• Selection of the Layering/Sintering process:
Sintering: if selected, enables the sintering process, when starting a job.
•
Layering: if selected, enables layering, when starting a job.
•
• Selection of the layers:
• Layer "_start_" to
field to complete individually them (a numeric keypad will be displayed).
• Optional: the button
when producing the first layers step-by-step). The button
fills the _end_ layer with the last layer value.
• The button "Aiming"
• The button allows to pause the job (see section "Interrupt a job" on page 45).
• The button allows to start the job (according to the selections
When activated, the confirmation window appears :
To start a job, proceed as following:
Select and configure the settings on the Launching area,
1.
2. Click on .
Validate
3. Click on either
functions (B) or on Quit
If some warning conditions occure, the confirmation window will differ (see section Manufacturing launch
warnings on page 45) .
To overcome O2 level variation around the fume safety setting, the job will start only if the oxygen level is
lower than 90% of the fume safety setting .
3D SYSTEMS, INC.
"_end_": the numbers of the first and last layer must be indicated. Click on the corresponding
"+1" _start_
increases the
sets the laser in no-power mode : the laser will sinter (without power) with a red beam.
(A) to confirm, or on one of the
(C) to cancel. Refer to the next paragraph for the delay start functions detail.
1
2
Start cycle
sequence (i.e gas ON...) when starting a job.
End cycle
sequence (i.e plate unclamping...) when job is finished.
layer by one and duplicate this value for the
" ...]" increases the
Start/End cycles and
B
C
A
Delay start
43
_end_
layer (useful
_start_ layer by one, and automatically
Layering/Sintering
3
process).
