3D Systems ProX DMP 200 User Manual page 42

2. During the automatic cycle, the user is prompted to indicate if a standard 12mm plate is
used (2):
• If yes, click "Yes". Then the automatic actions will continue. When completed, click on
(4) to go to the next step.
• If a different 12mm plate is used, then select "No", and proceed the following step.
3. Position the sintering plate by using the window (3) (with the arrows, or by entering a
setpoint), so that the top of the sintering plate is leveled with the sleeve of the sintering
piston. Then confirm by clicking on Validate. The automatic cycle will then continue.
4. When the automatic cycle is completed, the zero sintering value is displayed (4). Click on
Next (5) to go to the next step.
Step 5 : Powder loading
The Powder loading step is performed manually:
1. Perform the actions (1) by using the available
commands (2) and the external control panel.
Consult the section "Loading the feeding piston"
on page 60 for details.
2. When manual actions completed, click on
to go to the next step.
Step 6 : Powder bed
Powder bed
The step will allow to create the powder bed: the first powder layer will be deposited on the sintering plate.
1. Enter the iteration number of the powder bed
sequence, by using the "-" and "+" buttons (1).
2. Click on the Start button (2): this will launch the
automatic cycle.
3. Consult the section "Creating the powder bed" on
page 61.
4. When cycle completed, click on
the next step.
3D SYSTEMS, INC.
Next (3)
Next
(3) to go to
38
Next
3
2
3
1
2
3
2
1
