3-16 DATA FORMAT SCREEN
2.000.00 OO0Ocuw
Ts 10 nw
fr2108)
[TERMINAL MONITOR]
[DATA FORMAT SET] with MAIN DIAL
head => Data bit 7 bit (8 bid
BAUD => Baud Rate [3008] 6008 12008 24008
CODE => CR & LF Code CR only
To access this screen from MENU 1, push [F-6] "MENU" then
[F-1] "TERM" then [F-3] "FORMT." (p. 29)
3-17 Cl-V CONDITION SCREEN
usa MID BANK
2000.00 ooonw
Ts 10
REMOTE CONTROL CONDITION]
with MAIN DIAL
=> Default or User SET
(O1H-7FH)
=> Transceive with
1C-731/735
[Dev] faooR ] [Bawo] [Feo] [zai] [renw ]
To access this screen from MENU 1, push [F-6] "MENU" then
push [F-2] "CI-V." (p. 31)
LCD MONITOR SCREEN MENU 3
Sets the data length, baud rate and line feed command for
the terminal monitor screen,
"BIT" To select a character length of 7 of 8 bits,
[F-1] push and hold the switch then rotate the
main dial.
"BAUD" To select the baud rate, push and hold the
(F-2] switch then rotate the main dial.
To select the line feed command, CR or
CR + LF, push and hold the switch then
rotate the main dial.
CR: carriage return LF: line feed
Returns to the terminal monitor screen,
[F-6]
Sets the Cl-V remote control conditions.
Selects the standard CI-V condition for the
1C-R9000 or user programmed condition.
To select a default or user programmed
condition, push and hold the switch then
rotate the main dial.
"DE/U"
(F-1]
"ADDR" | To select the address number of the
[F-2] "USER" area, push and hold the switch
then rotate the main dial. O1H ~ 7FH
address numbers can be provided.
"BAUD"
[F-3]
Select the baud rate of the "USER" area,
push and hold the switch then rotate the
main dial.
"TRCV"
[F-4]
To turn the transceive function ON and
OFF, push and hold the switch then rotate
the main dial.
When operating the transceive function
with the IC-735, set the "731" parameter
to the "WITH" condition. To set the
"731" parameter, push and hold the switch
then rotate the main dial.
[F-5]
Data length:
1C-735 4 bytes,
another radio 5 bytes
"MENU"
[F-6]
Returns to the menu 1 screen.
