Canon imagePROGRAF iPF8000S Service Manual page 309

Code
Panel display
(last 4 digits)
(Large LCD)
2E15 Wrong paper type.
Stop: Stop Printing
Load/Eject:
Change Paper
Wrong paper type.
Replace paper
in cassette.
Wrong paper type.
Lift the release
lever and reload
the paper.
Stop: Stop Printing
Wrong paper type.
Lift the release
lever and reload
the paper.
Wrong paper type.
Lift the release
lever and reload
the paper.
Paper mismatch
Make sure media type
and paper size match
for the adjustment
print.
Wrong paper type.
Check paper type
setting in driver.
Online: Print
Stop: Stop Printing
Wrong paper type.
This type of media
is not compatible
with HP-GL/2.
Wrong paper feed
slot for this paper
type.
Press Load/Eject
and reload the
paper.
Wrong paper feed
slot for this paper
type.
2E16 Wrong paper type.
Check paper type setting on
computer.
Online: Print
Stop: Stop Printing
Wrong paper type
and size. Check
paper type and size
setting on computer.
Online: Print
Stop: Stop Printing
Wrong paper type
and size. Check
paper type and size
setting in driver.
Online: Print
Stop: Stop Printing
2E17 No cassette
detected.
Check the cassette.
2E18 Cannot load.
Press Load/Eject
and reload the
paper.
2E19 Cannot load.
Press Load/Eject
and reload the
paper.
2E1A Cannot load.
Press Load/Eject
and reload the
paper.
Panel display
Explanation/Detection sequence
(Small LCD)
Paper mismatch Paper mismatch (type) (on adjustment)
Press (lower arrow) To The second and subsequent sheets of paper
Replace have been fed as a paper type different
(Paper Type) from the first sheet when LF adjustment
(Paper Size) was made with cut sheet.
Loaded Paper
Check Type
Switch Paper
In Cassette
Loaded Paper
Check Type
Press (lower arrow) Key
and Reload
Driver: Chk Papr Paper mismatch (type)
Type Setting At the start of printing, paper type specified
Chk Paper Type in the job and the type of paper actually
Press Online loaded do not match, and [Stop] has been
selected for [Paper Mismatch Detection].
PaprTyp Mismatch
Prnt:PressOnline
Paper Feed Slot Paper mismatch (type)
SpcfdPapr NotFit A paper type that cannot be fed from the
Press (lower arrow) Key specified feeder slot has been specified.
and Reload
Paper Mismatch Paper mismatch (type)
Prnt:PressOnline The data type defined in the data and the
Check Paper type of actually loaded paper do not match.
Press Online Following the transmission of data in the
GARO format, all of the following
conditions have been met at the start of
printing:
-The paper type that has been set in the job
and the type of actually fed paper do not
match.
-[Stop] has been selected for [Paper
Mismatch Detection].
Cassette Cassette not installed
Undetected
Check Cassette
Press Online
Remove paper Paper not fed as far as the platen
Cannot Feed
Press (upper arrow) Key
Remove paper Feeding error
Cannot Feed LF out of synchronization for cut sheet
Press (upper arrow) Key
Remove paper Feeding error
Cannot Feed LF out of synchronization for cut sheet
Press (upper arrow) Key
Chapter 8
Remedial Action
Equalize the paper types for the first
and second sheets with each other in
adjustment printing.
Check the paper that is actually loaded
on the printer and the driver paper type
setting.
Check the feeder slot/cassette pick-up
setting.
Check the paper that is actually loaded
on the printer and the driver paper type
setting.
1. Check to see if the cassette itself is
properly loaded.
2. Check and replace sensor (I/O
mode).
Refeed the paper.
Refeed the paper.
8-21
