Chapter 4
4-4
4. Ink Tank unit Disassembly Flow
<Legend > c: Connector h: Hook s: Screw
Printer
Right circle cover (L) (h1)
Right circle cover (S) (h1)
Right side covers (s3, h2)
Left/right tank cover units
(s3)
Move the carriage to
above the platen
Manual ink drain
Drain the ink in subtanks
Remove the left/right
ink tube joints
Ink tank unit(c5, s2)
Automatic ink drain
Left/right tank cover units
(s3)
F-4-5
