Canon imagePROGRAF iPF8000S Service Manual page 16

Chapter 1
[19]
[20]
[1] Upper Cover
[2] Ink Tank Cover
[3] Ejection Slot
[4] Ejection Guide
[5] Output Stacker
[6] Roll Holder Slot
[7] Holder Stopper
[8] Roll Holder
[9] Paper Feed Slot
[10] Ejection Support
[11] Release Lever
1-2
[18] [17] [16]
F-1-2
T-1-1
[12] Stand
[13] Maintenance Cartridge Cover
[14] Maintenance Cartridge
[15] Operation Panel
[16] Expansion Board Slot
[17] Ethernet Port
[18] USB Port
[19] Accessory Pocket
[20] Media Take-up Unit Power Inlet
[21] Power Supply Connector
[22] Carrying Handles
[22]
[21]
