Canon imagePROGRAF iPF8000S Service Manual page 23

Detection functions (Carriage Printhead presence/absence detection: Yes
system) Carriage position detection: Yes
Carriage home position detection: Yes
Carriage cover open/closed detection: Yes
Carriage temperature detection: Yes
Printhead height detection: Yes
Non-discharging nozzle detection: Yes
Non-discharging nozzle backup feature: Yes
Detection functions (Paper path Paper presence/absence detection: Yes
system) Paper width detection: Yes
Skew detection: Yes
Paper release lever position detection: Yes
Remaining roll media detection: Yes
Feed roller rotation detection: Yes
Operating noise Operating: Approx. 50dB (A) or less
Standby: Approx. 35dB (A) or less
Operating environment Temperature: 5 to 35 degrees centigrade
Humidity: 10% to 90%RH
Print quality guaranteed Temperature: 15 to 30 degrees centigrade
environment Humidity: 10% to 80%RH
Power supply 100-240 VAC (50/60 Hz)
Power consumption (Maximum) During printing: Max. 190 W
Power consumption In power save (sleep) mode:
100-120 VAC : 5W or less (When IEEE1394 board installed, 10W or
less)
220-240 VAC : 6W or less (When IEEE1394 board installed, 11W or
less)
During standby: 1 W or less
Printer unit dimensions 1893mm x 975mm x 1144mm (with stand and output stacker)
(WxDxH)
Weight Approx. 135 kg (with stand and output stacker)
Chapter 1
1-9
