Chapter 1

1.2.4 Cutter Unit

The cutter unit that mounts on the carriage unit is disposable.
Replace the cutter unit when it gets dull.

1.2.5 Roll holder

The printer comes with a roll holder for paper tubes having an inside diameter of 2 inches as standard. It supports an optional roller holder for paper tubes having
an inside diameter of 3 inches.
Both roll holders clamp the paper tubes of roll media with an outside diameter of 150 mm or less from inside.

1.2.6 Stand

The stand is equipped with casters so that the printer can be easily moved.
1-4
[1]
[1]

Stand

F-1-5
F-1-6
[2]
F-1-7
[2] Stopper
0013-6369
0013-6371
0017-8299
