Canon imagePROGRAF iPF8000S Service Manual page 233

J3602
Pin Number Signal name
1 IO_ASIC_SDA
2 IO_ASIC_SCL
3 GND
4 H1-E-DATA-8-EV_B
5 OUT ENB
6 H1-D-HE-7_B
7 GND
8 H1-D-DATA-7-EV_B
9 GND
10 H1-D-DATA-6-EV_B
11 GND
12 H1-D-DATA-6-OD_B
13 GND
14 H1-D-HE-6_B
15 GND
16 H1-C-HE-5_B
17 GND
18 H1-C-DATA-5-OD_B
19 GND
20 H1-DSOUT2
21 H1-DSOUT1
22 GND
23 GND
24 H1_CLK_B
25 GND
26 H1_LT_B
27 GND
28 H1-C-DATA-5-EV_B
29 GND
30 H1-B-HE-3_B
31 GND
32 H1-C-DATA-4-EV_B
33 GND
34 H1-B-DATA-3-EV_B
35 GND
36 H1-B-DATA-2-EV_B
37 GND
38 H1-A-DATA-1-EV_B
39 GND
40 H1-A-HE-1_B
41 GND
42 H1-A-DATA-0-EV_B
43 GND
44 H1-A-HE-0_B
45 GND
46 H1-A-DATA-0-OD_B
47 GND
48 H1-A-DATA-1-OD_B
49 GND
50 H1-B-HE-2_B
T-6-23
IN/OUT Function
IN/OUT Head ROM controll signal(data)
IN/OUT Head ROM controll signal(clock)
- GND
OUT Even head(L) data signal 8(E)
OUT Head data enable signal
OUT Head(L) heat enable signal 7(D)
- GND
OUT Even head(L) data signal 7(D)
- GND
OUT Even head(L) data signal 6(D)
- GND
OUT Odd head(L) data signal 6(D)
- GND
OUT Head(L) heat enable signal 6(D)
- GND
OUT Head(L) heat enable signal 5(C)
- GND
OUT Odd head(L) data signal 5(C)
- GND
OUT Head temperature output signal 2
OUT Head temperature output signal 1
- GND
- GND
OUT Head(L) clock signal
- GND
OUT Head(L) latch signal
- GND
OUT Even head(L) data signal 5(C)
- GND
OUT Head(L) heat enable signal 3(B)
- GND
OUT Even head(L) data signal 4(C)
- GND
OUT Even head(L) data signal 3(B)
- GND
OUT Even head(L) data signal 2(B)
- GND
OUT Even head(L) data signal 1(A)
- GND
OUT Head(L) heat enable signal 1(A)
- GND
OUT Even head(L) data signal 0(A)
- GND
OUT Head(L) heat enable signal 0(A)
- GND
OUT Odd head(L) data signal 0(A)
- GND
OUT Odd head(L) data signal 1(A)
- GND
OUT Head(L) heat enable signal 2(B)
Chapter 6
6-11
