Canon imagePROGRAF iPF8000S Service Manual page 236

Chapter 6
J103
Pin Number Signal name
29 GND
30 H1-DSOUT1
31 H1-DSOUT2
32 GND
33 H1-C-DATA-5-OD_B
34 GND
35 /H1-C-HE-5_B
36 GND
37 /H1-D-HE-6_B
38 GND
39 H1-D-DATA-6-OD_B
40 GND
41 H1-D-DATA-6-EV_B
42 GND
43 H1-D-DATA-7-EV_B
44 GND
45 /H1-D-HE-7_B
46 GND
47 H1-E-DATA-8-EV_B
48 GND
49 IO_ASIC_SCL
50 IO_ASIC_SDA
J104
Pin Number Signal name
1 GND
2 GND
3 VH_MONI4
4 GND
5 GND
6 GND
7 H0-C-DATA-4-OD_B
8 GND
9 /H0-C-HE-4_B
10 GND
11 H0-B-DATA-3-OD_B
12 GND
13 H0-B-DATA-2-OD_B
14 GND
15 /H0-B-HE-2_B
16 GND
17 H0-A-DATA-1-OD_B
18 GND
19 H0-A-DATA-0-OD_B
20 GND
21 H0-DASH LICC2_B
22 GND
23 H0-E-DATA-9-EV_B
24 GND
25 /H0-E-HE-9_B
26 GND
27 H0-F-DATA-10-EV_B
28 GND
29 H0-F-DATA-11-EV_B
30 GND
31 /H0-F-HE-11_B
32 GND
33 H0-F-DATA-11-OD_B
34 GND
35 /H0-F-HE-10_B
36 GND
37 H0-E-DATA-9-OD_B
38 GND
39 H0-F-DATA-10-OD_B
6-14
IN/OUT Function
- GND
OUT Head(L) temperature output signal 1
OUT Head(L) temperature output signal 2
- GND
IN Odd head(L) data signal 5(C)
- GND
IN Head(L) heat enable signal 5(C)
- GND
IN Head(L) heat enable signal 6(D)
- GND
IN Odd head(L) data signal 6(D)
- GND
IN Even head(L) data signal 6(D)
- GND
IN Even head(L) data signal 7(D)
- GND
IN Head(L) heat enable signal 7(D)
- GND
IN Even head(L) data signal 8(E)
- GND
IN/OUT Head ROM control signal(clock)
IN/OUT Head ROM control signal(data)
T-6-27
IN/OUT Function
- GND
- GND
OUT VH control signal 4
- GND
- GND
- GND
IN Odd head(R) data signal 4(C)
- GND
IN Head(R) heat enable signal 4(C)
- GND
IN Odd head(R) data signal 3(B)
- GND
IN Odd head(R) data signal 2(B)
- GND
IN Head(R) heat enable signal 2(B)
- GND
IN Odd head(R) data signal 1(A)
- GND
IN Odd head(R) data signal 0(A)
- GND
IN Head analogue switch A/D trigger signal
- GND
IN Even head(R) data signal 9(E)
- GND
IN Head(R) heat enable signal 9(E)
- GND
IN Even head(R) data signal 10(F)
- GND
IN Even head(R) data signal 11(F)
- GND
IN Head(R) heat enable signal 11(F)
- GND
IN Odd head(R) data signal 11(F)
- GND
IN Head(R) heat enable signal 10(F)
- GND
IN Odd head(R) data signal 9(E)
- GND
IN Odd head(R) data signal 10(F)
