EcoDesign Disclosures

Figure 63: AIC Removal

Step 7 :

Using a T10 Torx screwdriver, remove the three (3) screws holding the IO Module (IOM) riser PCB

to the PCIe support bracket:

To prevent damage to the cards and connectors, do not twist or torque

Caution:

the cards when removing them.

1. EU EcoDesign Disclosures

1.5 IO Module (IOM) Disassembly
