EcoDesign Disclosures
Figure 25: Rack Ear Cover Screw Locations
b. Pull each cover away from its rack ear to remove it:
Figure 26: Rack Ear Cover Removal
c. The left rack ear has a system LED PCBA mounted to it. Using a T7 Torx screwdriver, remove
the two (2) screws holding the PCBA to the rack ear:
1. EU EcoDesign Disclosures
1.4 OpenFlex ™ Data24 Disassembly
17
