ADV7181B
Mode 3 525i/625i YPrPb Input (Y on AIN1, Pr on AIN3, and Pb on AIN5)
All standards are supported through autodetect, 8-bit, ITU-R BT.656 output on P15 to P8.
Table 88. Mode 3 YPrPb Input 525i/625i
Register Address
0x00
0x1D
0x0F
0x3D
0x3F
0x50
0xC3
0xC4
0x0E
0x52
0x58
0x77
0x7C
0x7D
0x90
0x91
0x92
0x93
0x94
0xCF
0xD0
0xD6
0xE5
0xD5
0xE4
0xE9
0x0E
