ADV7181B
Table 73. NTSC Line Enable Bits and Corresponding Line
Numbering
Line Number
Line[3:0]
(ITU-R BT.470)
0
10
1
11
2
12
3
13
4
14
5
15
6
16
7
17
8
18
9
19
10
20
11
21
12
22
13
23
14
24
15
25
0
273 (10)
1
274 (11)
2
275 (12)
3
276 (13)
4
277 (14)
5
278 (15)
6
279 (16)
7
280 (17)
8
281 (18)
9
282 (19)
10
283 (20)
11
284 (21)
12
285 (22)
13
286 (23)
14
287 (24)
15
288 (25)
Downloaded from
Elcodis.com
electronic components distributor
Enable Bit
Comment
GDECOL[0]
Gemstar
GDECOL[1]
Gemstar
GDECOL[2]
Gemstar
GDECOL[3]
Gemstar
GDECOL[4]
Gemstar
GDECOL[5]
Gemstar
GDECOL[6]
Gemstar
GDECOL[7]
Gemstar
GDECOL[8]
Gemstar
GDECOL[9]
Gemstar
GDECOL[10]
Gemstar
GDECOL[11]
Gemstar or
closed caption
GDECOL[12]
Gemstar
GDECOL[13]
Gemstar
GDECOL[14]
Gemstar
GDECOL[15]
Gemstar
GDECEL[0]
Gemstar
GDECEL[1]
Gemstar
GDECEL[2]
Gemstar
GDECEL[3]
Gemstar
GDECEL[4]
Gemstar
GDECEL[5]
Gemstar
GDECEL[6]
Gemstar
GDECEL[7]
Gemstar
GDECEL[8]
Gemstar
GDECEL[9]
Gemstar
GDECEL[10]
Gemstar
GDECEL[11]
Gemstar or
closed caption
GDECEL[12]
Gemstar
GDECEL[13]
Gemstar
GDECEL[14]
Gemstar
GDECEL[15]
Gemstar
Rev. B | Page 56 of 100
Table 74. PAL Line Enable Bits and Corresponding Line
Numbering
Line Number
Line[3:0]
(ITU-R BT.470)
12
8
13
9
14
10
15
11
0
12
1
13
2
14
3
15
4
16
5
17
6
18
7
19
8
20
9
21
10
22
11
23
12
321 (8)
13
322 (9)
14
323 (10)
15
324 (11)
0
325 (12)
1
326 (13)
2
327 (14)
3
328 (15)
4
329 (16)
5
330 (17)
6
331 (18)
7
332 (19)
8
333 (20)
9
334 (21)
10
335 (22)
11
336 (23)
Enable Bit
Comment
GDECOL[0]
Not valid
GDECOL[1]
Not valid
GDECOL[2]
Not valid
GDECOL[3]
Not valid
GDECOL[4]
Not valid
GDECOL[5]
Not valid
GDECOL[6]
Not valid
GDECOL[7]
Not valid
GDECOL[8]
Not valid
GDECOL[9]
Not valid
GDECOL[10]
Not valid
GDECOL[11]
Not valid
GDECOL[12]
Not valid
GDECOL[13]
Not valid
GDECOL[14]
Closed caption
GDECOL[15]
Not valid
GDECEL[0]
Not valid
GDECEL[1]
Not valid
GDECEL[2]
Not valid
GDECEL[3]
Not valid
GDECEL[4]
Not valid
GDECEL[5]
Not valid
GDECEL[6]
Not valid
GDECEL[7]
Not valid
GDECEL[8]
Not valid
GDECEL[9]
Not valid
GDECEL[10]
Not valid
GDECEL[11]
Not valid
GDECEL[12]
Not valid
GDECEL[13]
Not valid
GDECEL[14]
Closed caption
GDECEL[15]
Not valid
