Mode 2 S-Video Input (Y on AIN1 and C on AIN4)
All standards are supported through autodetect, 8-bit, ITU-R BT.656 output on P15 to P8.
Table 87. Mode 2 S-Video Input
Register Address
0x00
0x15
0x1D
0x0F
0x3A
0x3D
0x3F
0x50
0xC3
0xC4
0x0E
0x50
0x52
0x58
0x77
0x7C
0x7D
0x90
0x91
0x92
0x93
0x94
0xCF
0xD0
0xD6
0xE5
0xD5
0xD7
0xE4
0xE9
0xEA
0x0E
Downloaded from Elcodis.com electronic components distributor
Register Value Notes
0x06 S-Video input.
0x00 Slow down digital clamps.
0x40 Enable 28 MHz crystal.
0x40 TRAQ.
0x12 Power down ADC 2.
0xC3 MWE enable manual window.
0xE4 BGB to 36.
0x04 Set DNR threshold.
0x41 Manual mux AIN2 to ADC0 (0001), AIN4 to ADC1 (0100).
0x80 Enable manual muxing.
0x80 ADI recommended programming sequence. This sequence must be followed exactly when
setting up the decoder.
0x20 Recommended setting.
0x18 Recommended setting.
0xED Recommended setting.
0xC5 Recommended setting.
0x93 Recommended setting.
0x00 Recommended setting.
0xC9 Recommended setting.
0x40 Recommended setting.
0x3C Recommended setting.
0xCA Recommended setting.
0xD5 Recommended setting.
0x50 Recommended setting.
0x4E Recommended setting.
0xDD Recommended setting.
0x51 Recommended setting.
0xA0 Recommended setting.
0xEA Recommended setting.
0x3E Recommended setting.
0xE3 Recommended setting.
0x0F Recommended setting.
0x00 Recommended setting.
Rev. B | Page 89 of 100
